HOT SALE HYSOON 23HP 200KG capacity multifuncional HY380 mini loader for sale
1.HYSOON HY380 mini loader for sale specification :
1. HY380 mini loader engine : American Briggs&Stratton engine 23HP/ Kohler engine
2. HY380 mini loader pump : double gear pump , Italy Hansa pump for optional
3. HY380 mini loader valves: Advanced Italian Hydrocontrol valves
4. HY380 mini loader motor: INI drive motor /White drive motor
5.HY380 mini loader Engine filter : Donaldson cyclonic air filter
6. All parts electrophoresis avoid rusting
HYSOON HY380 mini loader for sale is a multifunctional machine , it widely used in landscaping, gardens, Hire market , Fenching , Industry , Construction , Contractors , Farm , Mining and many other industries .
There are various mini loader attachments , mini skid steer attachments that can be used on HY380 mini loader such as sweeper, auger,lawn mower, snow blower, stump grinder, tree spade,bucket,backhoe, hydraulic breaker, pallet forks, angle broom, trencher, ripper, tillers, grapple , rotary tiller ect . you can use one HY380 min loader to finish different works , it's a good Choice.
HY380 mini loader for sale |
|
|
Item | Metric | Inch |
Max working height(A) | 2115 mm | 83.3 inch |
Max pin height (B) | 1856 mm | 73.1 inch |
Max dump height(C) | 1460 mm | 57.5 inch |
The highest point discharge distance(D) | 388 mm | 15.3 inch |
Bucket swing angle(β) | 55° | 55° |
Bucket unloading angle(γ) | 30° | 30° |
Opening-closing angle(θ) | 25° | 25° |
Angle of departure(α) | 8° | 8° |
Total height (H) | 1205 mm | 47.4 inch |
The height from the ground(F) | 90 mm | 3.5 inch |
Wheelbase (G) | 636 mm | 25.0 inch |
No bucket length(J) | 1752 mm | 69.0 inch |
Total width (W) | 1033 mm | 40.7 inch |
Bucket width (K) | 980 mm | 38.6 inch |
Total length(L)(with bucket) | 2206 mm | 86.9 inch |
Turning radius (R) | 1307 mm | 51.5 inch |
2. HYSOON HY380 mini loader for sale pictures:
HY380 mini loader can do different works by quick change different accessories .
Other brand like Dingo ,Toro accessories can also suitable for HY380 .
.Package for HYSOON HY380 mini loader for sale
If LCL , use plywood & iron frame package , It’s very strong to protect HY380 mini loader
If FCL , direct load into the container : 20'ft container: 8 unit ; 40'ft container: 16unit
Taian Hysoon Machinery Co., LTD is the first-class company engaged in the research, development and manufacture of mini skid steer loaders , mini loaders , skid steer loaders with accessories. Different models:
HY380 mini skid steer loader, HY280 Mini digger, HY200 articulated mini loader, HY700 skid steer loader like bobcat,
HY850 skid steer loader .
Following is exhibition and Customers visiting of mini skid steer loaders , mini loaders and skid steer loaders
