TRACTOR DISC PLOW/PLOUGH
LF-BQX-1.1 |
LF-BQX-1.3 |
LF-BQX-1.5 |
LF-BQX-1.7 |
LF-BQX-1.9 |
LF-BQX-2.3 |
||||||
Working width(m) |
1.1M |
1.3M |
1.5M |
1.7M |
1.9M |
2.3M |
|||||
Working depth(mm) |
80-120MM |
||||||||||
No.of disc(pcs) |
12 |
14 |
16 |
18 |
20 |
24 |
|||||
Disc Dia.(mm) |
460MM/ 18'‘ |
||||||||||
Weight(kg) |
200 |
220 |
240 |
260 |
310 |
360 |
|||||
Tractor power(hp) |
12-20 |
15-25 |
25-35 |
30-35 |
35-45 |
50-60 |
|||||
Linkage |
3 Point linkage, CAT I |
||||||||||
DISC HARROW
The disc harrow is used for breaking up the ground, shattering soil lumps and mixing crop residues into soil as green manures.
This harrow is mounted to tractor by 3 point linkage, the whole straucture is enough strong to perform excellently in steep land
with high speed.
Product details:
• 1. 28×28 square harrow shaft used, 200mm spacing between discs
• 2. High Carbon disc blade hardness: 38-44 HRC, assuring the toughness and wear ability of disc blade.
• 3. Compact harrow structure, convenient for assembly and adjustment
• 4. High harrowing speed and efficiency when three point mounted with tractor rear
• 5. Especially performing well in rugged land with more steep slopes
• 6. Disc harrow adopting using bearing combinations with a grease filling hole on it, keeping sand or soil from going into
bearing to cause break down and maintaining conveniently
Model |
1LX-220 |
1LX-320 |
1LX-420 |
Weight(Kg) |
65 KG |
105 KG |
155KG |
working Depth(mm) |
120-160 |
120-160 |
120-160 |
Power Required(Min/Max) |
15-20HP |
25-35HP |
30-45HP |
Packing size (mm)in 10 |
2200*1000*1100 |
2200*1000*1100 |
2200*1000*1100 |
Why Choose LEFA
Changzhou LEFA Industry & Trade Co., Ltd., is a professional manufacturer and exporter of whole set of agriculture machines and garden tools. Our company was established since 2003 with Hanma Industry Company.
Our main products include rotovator, flail mower, finishing mower, topper mower, wood chipper, plow, cultivator, potato harvester/ planter and Japanese tractor parts, etc. Due to our super International quality standard and rapide & excellent after-sales service, LEFA machines are greatly popular in various markets around the world, and already reached to Europe, North America, South America,Australia, almost covers 80 countries in World.
LEFA always believe that we will take better farming life to you by top-quality laser cutting machine & CNC bending machine & professional paint-spraying & strong welding.
1.Professional team with rich experience
2.Powerful factory strength with CE certification
.
3.Best after-sales service
Alibaba Trade Assurance Service
Changzhou LEFA--Memeber of Alibaba Trade Assurance, it can safegurd your payment and ensure order delivery & product quality, We have Trade Assurance Amount USD200000 granted by Alibaba. Welcome to directly place order by Alibaba.
★.Hello Virginia,
I received potato harvester and mower yesterday. The potato harvester is quite more good-looking than I imagined and I believe it will well work too.
The mower looks very good too. I will report back when I've used them and let you know what I think!
David
★.Hello.
Yes we have the harvester and we gave it a little test. Looks like it should work great once harvest time comes around.
We will get a video for you when we harvest.
Thank you
Chris
★.Dear Leslie
We have received flail mower EFD95, we want to give a good compliment for your packaging, it looks perfect.
I also showed HANMA machines to my friends, they have asked some questions about your machines and parts, then place an order after having figured out all.
Thanks
★.Hi, Cay
We have received flail mower EFD95, we want to give a good compliment for your packaging, it looks perfect.
I also showed LEFA machines to my friends, they have asked some questions about your machines and parts, then place an order after having figured out all.
Thanks
Jake
Q1. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery if your order is more than USD5000. We'll show you the photos of the products and packages before you pay the balance.
Q2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q3. How about your delivery time?
A: Generally, it will take 20-30 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you accept OEM & ODM?
A: Yes, we can accept ODM & OEM to meet your special requirements.
Q5. How to buy LEFA machines?
A.Inquiry ---------> Quotation -------->Price reasonable ------->Check with specification ----->Proforma Invoice sent ------------>Payment made -------> Producing the items ------->Product shipment -----------> Customer confirm.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery. If you need, we can send testing picture for your reference
Q7: Do you have stock for all items?
A:In general, we have some stock, while if you need a bulk order, we still need time to produce it. Of course, we will inform all details before your payment.
Q8: What is your terms of payment?
A: T/T, L/C, Paypal,Western Union
