NT2000A EUI EUP Controller Injector Test Bench EUI/EUP Tester/Simulator common rail pump tester

EUI EUP tester/controller EUS2000
The repair tester is designed to perform repair tests for different type of Electronic Unit Injectors(EUI) and Electronic Unit Pumps(EUP). The tester consists of a mechanical cam box with specified EUI/EUP adapter kits and electronic controller.
The cam box will be driven by a standard high pressure fuel injection pump test bench.
The EUP/EUI being tested will be installed in the cam box with the adapter. The electronic controller provides signal to drive the EUP solenoid
synchronous with cam shaft rotation. The EUP fuel outlet is connected through high pressure fuel line to an injector.
The EUP fuel injection quantities can be checked at given speeds and loads to judge its quality.

1.One cambox for all major EUI/EUP models with corresponding adapters and camshafts
2.Cambox mounting height 125mm (from the center of camshaft to bench mounting platform) for Boch type pump test bench
3.Controller is designed for three kinds of drive mode
4.Low voltage for most battery voltage driven EUI/EUP
5.High voltage for Cat EUI
6.Cumming Celect EUI
7.Adjustable Begin of Injection (BOI) in Crank Angle Degrees
8. Adjustable Injection Period (PW) in Crank Angle Degrees
9. Engine standard cam lobe designs
10. Four levels of cam lift
11.Constant velocity cam lobe to generate higher injection pressure, 3 times higher than cheap eccentric cams

Nanyang NanTai Experimental Equipment Co.,Ltd is a joint-stock enterprise
that produces common rail test bench, traditional diesel fuel injection pump
test bench, Nozzle Tester, and sells spares parts for repairing variety of
electronic diesel injection systems to serve the automobile aftermarket all
over the world.
The company pursues high standard manufacturing and qualified products. All
the products have passed the quality system certification of ISO9001:2008 &
CE certificate and entered European market. Depending on the stable and
lasting capabilities, our products are well known to international market such
as Russia, Mongolia, Bulgaria ,Albania, Argentina, South Africa, Germany,
Romania, Ukraine, Haiti, Iraq, Britain, Brazil, Malaysia and etc
