HEUI/CRI-NT800 is high pressure common rail injector and middle pressure combination test bench,
which is originated by our company, Computer automatically test many types of Bosch Denso
Delphi and Siemens’s solenoid valve and piezo injector, also can test many types of CAT HEUI injectors.
Measuring the injected fuel quantity & return volume under sealing performance, idling ,
pre-injection and middle-speed,full-loaded, and so on status.
User can add , edit and print the data by themselves.
Equipped with high precision flow sensor to confirm the testing precision.
Injector testing
1.Cleaning: High pressure cleaning for the impurities inside the injectors.
2.Testing the injection and return volume under VL, TL, LL, VE and VE2 status.
3.Atomization test: to judge whether the injector is blocked through the atomization effect.
4.Sealing test: check whether nozzle, nozzle cap nut and solenoid valve leaks oil.
5.Test solenoid valve injectors of different models automatically
6.Test piezo injectors of different models automatically
7.Test Piezo injector assembly of large resistance value(>2.5 Ohm).
8.HEUI/CRI-NT800 is high pressure common rail injector and middle
pressure combination test bench, which is originated by our company, can test
CAT 3126
- CAT 3408
- CAT C7/C9
- Ford PowerStroke 6.0L
Configuration.
- Equip industrial air conditioner to ensure the oil temperature at 40±2 degree
- Equip original Bosch common rail system, rail pressure is controlled by DRV and ZME at ±0.5Mpa.
- Equipped with original Germany KOBOLD flow sensor to make sure the testing precision.
- Equip original Bosch CP1 pump.
- Compact universal stand,could test solenoid valve injector or electric piezo injector.
- Normal rail pressure 0-1800bar to make sure the testing precision (optional: rail pressure 0-2500bar)
- For compressor cooling system, normally we use compressor made in China.
- You can also choose SC15CL series compressor provided by Danfoss company,
- it comply with EU EC842/ 2006 fluorine gas law and the EU 2006/40/EC Directive (optional)
System advantage.
1.Full automatic operation with Windows XP system.
2.Embedded industrial computer system: high speed operation and stable performance.
3.Inset test plan same as original Bosch test bench, test accuracy of our machine can be compared with Bosch bench.
4..Powerful database of over 1000 kinds of Bosch, Delphi, Denso and Siemens injectors.
5..Separate management of injector and pump database with memory function.
The database can be edited, saved, modified and regularly updated.
6.Users can choose to test step by step or continuous test
7.Users can choose to take the automatic judgment by computer or by themselves.
8.Self-protection under overheat, oil mist, overpressure and low oil level. It will be showed by the indicator lamp.
9..Support multi-language version such as Chinese, English, German, Spanish, French, Russian etc.
10.Remote control is convenient for service and software upgrade.
11.Support customized products and application.
Power supply:
We provide three types of model three-phase, 380V/50Hz,
three-phase 220V/60Hz and two-phase 220V/60Hz in convenient for the different need of power supply in different countries.
Nanyang NanTai Experimental Equipment Co.,Ltd is a joint-stock enterprise
that produces common rail test bench, traditional diesel fuel injection pump
test bench, Nozzle Tester, and sells spares parts for repairing variety of
electronic diesel injection systems to serve the automobile aftermarket all
over the world.
The company pursues high standard manufacturing and qualified products. All
the products have passed the quality system certification of ISO9001:2008 &
CE certificate and entered European market. Depending on the stable and
lasting capabilities, our products are well known to international market such
as Russia, Mongolia, Bulgaria ,Albania, Argentina, South Africa, Germany,
Romania, Ukraine, Haiti, Iraq, Britain, Brazil, Malaysia and etc
Q: Are you trading company or manufacturer ?
A: We are test bench assembling factory. We have had test bench for 20 years.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: How about the use of maintenance technology and equipment ?
A:We have free training about test bench,injector and pump maintenance.
Q: Why should I choose your product?
A: We can provide you the best quality and the most competitive price ,and we have our own engineer, if you have any requirements you can contact us directly.
