Acrel 300286.SZ AMC96-E4/KC 3P3W 3P4W Multifunction Harmonic Energy Meter With CE Approval
US$ 74 - 74
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Acrel
Place of Origin:
Jiangsu, China
Model Number:
AMC96-E4/KC
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Acrel AM2-V Non-electricity Protection Feeder Protection Protection RelayUS$ 207.2 - 207.2MOQ: 1 Piece -
Acrel AM2-V Earth Fault Protection on Low Voltage Side Feeder Protection Protection RelayUS$ 207.2 - 207.2MOQ: 1 Piece
-
Acrel AM2-V Post-accelerated Overcurrent Protection User Substation Protection RelayUS$ 207.2 - 207.2MOQ: 1 Piece
-
Acrel AM2-V Overcurrent IDMT User Substation Protection RelayUS$ 207.2 - 207.2MOQ: 1 Piece
-
Acrel AM2-V Remote Control Power Monitoring and Protection Protection RelayUS$ 207.2 - 207.2MOQ: 1 Piece
Brand Name
Acrel
Place of Origin
Jiangsu, China
Model Number
AMC96-E4/KC
Phase
Three Phase
Output Voltage
Pulse output
Operating Temperature
-10℃-55℃
Dimensions
96*96 *92mm
Display Type
Digital Only
Accuracy Class
Class1
Measuring Energy Range
0-999999.99kwh
Product Description
General
AMC series intelligent power collection and monitoring device is a smart meter designed for power monitoring needs of power systems, industrial and mining enterprises, utilities, and intelligent buildings. it integrates measurement of power parameters(such as sigle phase or three phase current, voltage, and active power). Power, reactive power, apparent power, frequency, power factor and power monitoring and assessment management. At the same time, it has a variety of peripheral interface functions for users to choose: with RS485 communication interface, MODBUS-RTU protocol can meet the needs of communication network management;4-20mA analog output can correspond to measured electrical parameters, meet DCS such interface requirements; with switch input and relay output can realize the function of "remote signal" and "remote control" of circuit breaker switch.High-brightness LED/LCD display interface,parameter setting and control through buttons, ideal for real-time power monitoring systems. Can directly replace conventional power transmitters and measuring instruments. As an intelligent, digital front-end asquisition component, the instrument has been widely used in various control system, SCADA systems and energy management systems.
Technical Parameters
Model |
AMC96L-E4/KC |
||
Network |
3 phase 4 wire |
||
voltage |
measuring range |
10-230V Phase voltage |
|
15-400v Phase to phase |
|||
overload |
instant 2 times/1s |
||
current |
measuring range |
5A input,primary input current0-9999A |
|
overload |
instant 1.2times,instant 10times/1s |
||
frequency |
45hz-65hz |
||
auxiliary power supply |
AC |
85-265V |
|
DC |
100-350V |
||
accuracy |
current,voltage |
0.5s |
|
power,energy |
1s |
||
power consumption |
＜5VA |
||
switching value input |
dry contact input,and built-in power supply |
||
relay output |
3A 250VAC/3A 30VDC |
||
environment |
working temperature |
-10℃-55℃ |
|
storage temperature |
-20℃-70℃ |
||
relative humudity temperature |
≤93%（non-condensing） |
||
altitude |
≤2500m |
||
electromagnetic compatibility |
electrical fast transient |
4kv 5kHz |
|
electrostatic discharge |
contact 6kv/air 8kv |
||
RF electromagnetic field |
10v/m |
||
Communication |
RS485 |
||
Dimension
