japan ntn bearing HK2218 robot needle roller bearing HK 2218 RS size 22x28x18mm
Needle roller bearings are bearings with cylindrical rollers that are small in diameter relative to their length. The modified roller/raceway profile prevents stress peaks to extend bearing service life.
BHR supplies needle roller bearings in many different designs, series and in a wide range of sizes, which make them appropriate for a wide variety of operating conditions and applications.
1. Needle roller and cage assembly
2. Drawn cup needle roller bearings
3. Needle roller bearings with machine rings
4. Alignment needle roller bearings
5. Universal joint bearings
6. Combined needle roller bearings
7. Needle roller thrust bearings
8. Cam follower, track rollers
Specifications:HK2218 ntn bearing drawn cup needle roller bearing | |
Fw |
22mm |
D |
28mm |
C |
18mm |
Mass |
22.5g |
Bearing number of row |
single row needle roller bearing |
Bearing material |
steel bearing, stainless steel bearing |
Bearing cage type |
iron cage, flat cage |
Bearing closure type |
open ends |
Needle roller bearing size
| Shaft | Bearing | Mass | Dimensions (mm) | Basic Load Ratings | Limiting | ||||
| Diameter | P.No. | Fw | D | C | r | Cr | Cor | Speed | |
| mm | g | min. | kN | kN | rpm | ||||
| 5 | NK 5/10TN | 3.1 | 5 | 10 | 10 | 0.15 | 2.5 | 2 | 37000 |
| NK 5/12TN | 3.7 | 5 | 10 | 12 | 0.15 | 3.05 | 2.99 | 37000 | |
| 6 | NK 6/10TN | 4.7 | 6 | 12 | 10 | 0.15 | 2.33 | 2.2 | 33000 |
| 6 | NK 6/12TN | 5.7 | 6 | 12 | 12 | 0.15 | 3.3 | 3.45 | 33000 |
| 7 | NK 7/10TN | 6.9 | 7 | 14 | 10 | 0.3 | 3.33 | 3.15 | 31000 |
| NK 7/12TN | 8.2 | 7 | 14 | 12 | 0.3 | 4.19 | 4.24 | 31000 | |
| 8 | NK 8/12TN | 8.7 | 8 | 15 | 12 | 0.3 | 4.1 | 4.3 | 29000 |
| NK 8/16TN | 12 | 8 | 15 | 16 | 0.3 | 4.9 | 5.4 | 29000 | |
| 9 | NK 9/12TN | 10.3 | 9 | 16 | 12 | 0.3 | 4.75 | 5.3 | 28000 |
| 10 | NK 10/12 | 10 | 10 | 17 | 12 | 0.3 | 5.01 | 5.82 | 27000 |
| NK 10/16 | 13 | 10 | 17 | 16 | 0.3 | 6.51 | 8.12 | 27000 | |
| 12 | NK 12/12 | 12 | 12 | 19 | 12 | 0.3 | 6.4 | 7.1 | 25000 |
| NK 12/16 | 16 | 12 | 19 | 16 | 0.3 | 9.1 | 11 | 25000 | |
