Home > Industrial Equipment & Components > Power Transmission Parts > Speed Reducer > 2017 Hot Sell Quality Worm Gear Motor
2017 Hot Sell Quality Worm Gear Motor
US$ 70 - 370
MOQ: 20 Sets
Key Specifications
Get Latest Price
Brand Name:
Julante
Place of Origin:
Zhejiang, China
Model Number:
CH-40-1500-30-S
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1500W 2200W 3700W Horizontal Type 3 Phase Helical Reduction Gear MotorUS$ 70 - 370MOQ: 20 Sets -
Original Taiwan Type Horizontal Type 3 Phase Helical Gear MotorUS$ 70 - 370MOQ: 20 Sets
-
Factory Supplier Siemens Helical Geared MotorsUS$ 32.43 - 35.02MOQ: 10 Pieces
-
Factory Wholesale Helical Gearbox ManufacturersUS$ 32.43 - 35.02MOQ: 10 Pieces
-
Promotion Seasonal Vibrator Needle 40mmUS$ 11 - 34MOQ: 10 Pieces
Brand Name
Julante
Place of Origin
Zhejiang, China
Model Number
CH-40-1500-30-S
Rated Power
1500W
Output Speed
40-100RPM
Input Speed
1450/50HZ, 1750/60HZ
Output Torque
2.6-1195N.M
Gearing Arrangement
Helical
2017 Hot Sell Quality Worm Gear Motor
Product Description
Helical gear motor reducers series are easy installation with low noise, high efficiency,light weight and compact design with satisfactory functions. The cutting edge technology provided by Taiwan,it is full with Taiwan Technology, quality is original. gear motor to be silence, high gear efficiency and easy maintenance.
Main Feathure:
- Quality & Silence
Every Gear Motor manufactured by Varitron, goes through a series of running tests to confirm within quality standard.
- Long service life with high precision manufacturing
Gears and shaft are manufactured with precision machined and carburized, then for precision tooth grinding or skiving assures long service life.
| Three Phase Gearmotor | Single Phase Gearmotor | ||
| Reducer | Gear Material | High Quality alloy steel machined and carburized with precision tooth grinding or skiving | |
| Housing | Aluminum alloy Casting for model 18,22,28. Cast Iron for model 40,50 | ||
| Lubrication | High Qually #0 Lubrication Oil (lubricated when shipped) | ||
| Ratio Range | 1/3 to 1/1800 | ||
| Motor | HP | 1/10HP to 5HP (75W to 3.7kW) | 1/10HP to 3HP (75W to 2.2kW) |
| Voltage | 208/415, 220/380, 220/440, 230/460, 240/480 | 110/220, 120/240 | |
| Frequency | 50 / 60 Hz | 50 / 60 Hz | |
| Enclose Type | Total Enclosed Fan Cooled, IP54 | Partially Enclosed Fan Cooled | |
| Staring | Full Voltage Drive On Line | Capacitor Start | |
| Housing | Auminum alloy | ||
| Insulation | F Grade Continuous S1 Duty | ||
Brake (optional) | Function | Safety Brake | |
| Voltage | DC90-110V with AC 220V Rectifier | DC90-110V with AC 110V Rectifier | |
| Environmental Specifications | Temperature | -10° - 40°C (14° - 104°F) | |
| Humidity | Under 90% RH (Non-Condensation) | ||
| Place | Indoor, Below sea level 1000 m (3,300 ft) | ||
Product Overviews
Applicantion:
Gear manufacturer for Agitators Mixers, Brewing and Distilling, Conveyors, Extruders, Food industry, Metal Mills, Hammer mills,Paper Mills,Lumber Industry, Rubber & Plastics Industries, Sewage Disposal Equipment, Oil Industry, Chemical plant, Textile Industry, Sugar Industry, Dry Dock Cranes.. and many more
FAQ
- Q: What is your business type ?
- A: Julante are experts of planetary gear reducer ,cone worm gearbox ,modular design helical gear motor , worm gearbox etc. A suitable model will offer to you according to your requirement , besides , also has proffessional technical team special in custom gearbox and gearbox repair .
- Q: How long can you provided products guarantee Period ?
- A: Based on different gearbox types , 12-18 months .
- Q: What's Certification your product acquiry ?
- A: DNV-ISO9001:2008 ,SGS ,CE etc. and new products patent .
- Q: How many technical employees in your company ?
- A: We have 10 engineers in our R&D Dep. , included 2 engineers who enjoy government 's allowance .
- Q: Where is your company & how to connect you ?
- A: Our factory located in Wenling,Zhejiang Province.
