   INVERTER TIG/MMA WELDING MACHINE(CCC & CE QUALITY CERTIFICATE APPROVED & ONE YEARS WARRANTY)

Model :TIG-160/180/200/250/300/400/500



MAIN TECHNICAL PARAMETER

MODEL          ITEM

TIG-180

TIG-200

TIG-250

TIG-300

TIG-400

TIG-500

Input power voltage,Frequency (V,HZ)

AC220V (SINGLE PHASE) ±10%   50/60 HZ

AC380V (THREE PHASE)±10% 50/60 HZ

Rated input power capacity (KVA)

3.9

4.5

6.3

8.3

13

19

No-load voltage (V)

56

56

54

54

55

60

Output current adjustment range (A)

10-180

20-200

20-250

20-300

20-400

20-500

Rated output voltage (V)

17.2

18

20

22

26

30

Rated duty cycle (%)

60

60

60

60

60

60

No-load loss (W)

40

40

40

60

100

100

Efficiency (%)

85

85

85

85

85

85

Pover factor (COSφ)

0.93

0.93

0.93

0.93

0.93

0.93

Gas post-flow time (S)

0-2.5

0-5

0-5

0-10

0-12

0-15

Arc force adjustment range (A)

-

0-60

0-60

0-60

0-100

0-130

Welding thickness (MM)

0.3-5

0.5-12

0.5-12

0.5-14

0.5-20

0.5-25

Current of MMA

10-160

20-200

20-220

20-230

20-380

20-400

Weight (KG)

8

13

19

21

35

37

Measurement (MM)

371x155x295

371x155x295

480x205x355

480x205x355

560x335x420

560x335x420

Insulation class

F

F

F

F

F

IP22

Protection class

IP23

IP23

IP23

IP23

IP23

IP23



 Standard Accessory List



1.A set of welding torch.



2.A set of electrode holder with fast coupling device.



3.A set of earth clamp with fast coupling device.



4.Two meters of gas carring hose with two clips.



5.A piece of tungsten.





Characteristic



    1.Small measurement, portable, multi-purpose with TIG&MMA function.



    2.HF arc staring with little current.



    3.ARC FORCE can be adjustable, stronger welding penetration with stable current,high speed of dynamic-response.
