0.25kw 1/3 HP 1400rpm single phase capacitor start induction motor /electric motor
our Taizhou Julante Factory is Specialized in induction Motor Production
Welcome to visit our website. http://www.zjjlt.en.china.cn/
We are a manufacturer but we can also supply the OEM service, products can be customized.
Specification:
Brand Name |
JULANTE |
Model Number |
JY series |
Type |
electric Motor |
Frequency |
50Hz |
Output Power |
0.18KW TO 1.1KW |
Phase |
Single-phase |
Certification |
CE, CCC, IS9001,CQC |
Rated voltage |
220v ±5% |
Efficiency |
IE1 |
Frame |
Cast Iron or aluminum |
Poles |
2 , 4 ,6 |
Ambient temperature |
-15° ℃ ≤0 ≤ 40 ℃ |
Altitude |
not exceeding 1000 Meters |
Duty |
Continuous running |
Insulation Class |
Class B/F |
Protection Class |
IP44 /IP54/IP55 |
Cooling Method |
IC0141 (total-enclosed fan-cooled type) |
Price |
USD |
Minimum Order Quantity |
10 Piece/Pieces, USD |
Packaging Details |
Foam,carton and plywood . We can pack according to your requirement . |
Delivery Time |
15-25 days after received the payment |
Payment Terms |
L/C,T/T |
Supply Ability |
20000 Piece/Pieces per Month |
Materials |
cast iron(63-355), aluminum (FRAME 63-160) |
Mounting types |
IMB3, IMB5,IMB35 |
Connection |
"Y" type for 3kW and downwards, "D" type for 3kW and upwards |
Relative humidity |
not higher than 90% |
Special motors can be designed according to customers' requirements | |
Technical data
| Type | Input Power | Current(A) | Power Factor | EFF(%) | Speed(r/min) | |
| KW | HP | |||||
| JY09B-2 | 0.18 | 1/4 | 2.15 | 0.76 | 50 | 2800 |
| JY09A-2 | 0.25 | 1/3 | 2.82 | 0.76 | 53 | 2800 |
| JY1B-2 | 0.37 | 1/3 | 3.74 | 0.75 | 60 | 2800 |
| JY1A-2 | 0.55 | 3/4 | 5.36 | 0.74 | 63 | 2800 |
| JY2B-2 | 0.75 | 1 | 6.81 | 0.77 | 65 | 2800 |
| JY2A-2 | 1.1 | 1.5 | 9.45 | 0.79 | 67 | 2800 |
| JY09B-4 | 0.12 | 1.6 | 1.7 | 0.63 | 48 | 1400 |
| JY09A-4 | 0.18 | 1.4 | 2.52 | 0.65 | 50 | 1400 |
| JY1B-4 | 0.25 | 1.3 | 3.2 | 0.67 | 53 | 1400 |
| JY1A-4 | 0.37 | 1.2 | 4.03 | 0.72 | 58 | 1400 |
| JY2B-4 | 0.55 | 3.4 | 5.12 | 0.74 | 66 | 1400 |
Inner packing:
1) Frame 63-100: carton boxes
2) Frame 112-315: wooden boxes
Mounting ways:IMB3(foot mounting),IMB5(flange mounting),IMB35,IMB14.
wiring diagram of three phase electric motor
BENIFITS TO CLIENT:
- Reliable operation
- High efficiency
- Energy-saving
- Low noise
- Long life
- Slight vibration
- Try our best to meet customers' requirements, including voltage and frequency etc.
- It is newly designed in conformity with the relevant rules of IEC standards
- Special rotor balance for reduced vibration
- Warranty: 12 months from date of delivery.
OPERATION CONDITIONS:
- Duty: S1
- Frequency: 50HZ
- Rated voltage: 220V±5%
- Protection class: IP55
- Cooling method: IC0141
- Ambient temperature: -15°C≤0≤45°C
- Alititude should be lower than 1000 meters above sea level
China Julante Motors Factory Advantages:
- Prompt Quotation.
- Competitive Price
- Guaranteed Quality
- Timely Delivery
- 100% Tested.
- Sincere and Professional Service.
- Outstanding Finishing Surface.
- Strictly and Perfect Management is guaranteed for Production.
- Specialized in Manufacturing and Supplying a wide range of Electric Motors since year 2002.
- Have Rich Experience and Strong ability to Develop New Products.
- Have Ability to Design the Products Based on Your Original Samples
Manufacturing process:
- Stamping of lamination
- Rotor die-casting
- Winding and inserting – both manual and semi-automatically
- Vacuum varnishing
- Machining shaft, housing, end shields, etc…
- Rotor balancing
- Painting – both wet paint and powder coating
- Motor assembly
- Packing
- Inspecting spare parts every processing
- 100% test after each process and final test before packi
detail show :
Wound rotor,cooper winding,good quality fan and fan covers,all good motor spare parts
free to contact us if you are interested in our electric motors.
