Help CenterHigh Cost Performance Linear Vibrating Screen
Related Products
-
High Capacity Linear Vibrating Screen Food Powder Separator MachineUS$ 900 - 1700MOQ: 1 Set -
High Efficiency Linear Vibrating Screen Separating Wood Powder Sieve MachineUS$ 900 - 1700MOQ: 1 Set
-
High Efficiency Linear Vibrating Screen for Sieving Food Separator MachineUS$ 900 - 1700MOQ: 1 Set
-
Sanyuantang Linear Vibrating Screen Chemical Fertilizer Sieve ShakerUS$ 900 - 1700MOQ: 1 Set
-
Sanyuantang Linear Vibrating Screen Baobab Powder Processing Sieve MachineUS$ 900 - 1700MOQ: 1 Set
Working Principle:
SY series linear vibration sieve is used as a source of vibration excitation by vibrating motor, so that the sieve material being thrown up and forward for linear motion ,in order to match reasonable sieve.There are several balls on the bottom of screen frame hit each other when vibrating, which can clear screen and avoid blocking effectively .
Application:
It is suitable for any dry material screening from 0.74mm-5mm., the largest particle size is 10mm.It is widely used in chemical, food, plastics, pharmaceuticals, metallurgy, glass, building materials, food, fertilizers, abrasives, ceramics and other industries.
1) Chemical industry: resin pigment, medicine, grease, paint, palette, etc.
2) Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry, etc.
3) Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
4) Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
5) Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc.
6) Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc.
Technical parameters
Model |
SYZ-520 |
SYZ-840 |
SYZ-1030 |
SYZ-1255 |
SYZ-1650 |
Dimension(mm) |
500*2000 |
800*4000 |
1000*3000 |
1200*5500 |
1600*5000 |
Granularity(mm) |
0.074-60 |
0.074-60 |
0.074-60 |
0.074-60 |
0.074-60 |
Speed(r/min) |
960 |
960 |
960 |
960 |
960 |
Amplitude |
4-8 |
4-8 |
4-8 |
4-8 |
4-8 |
Deck |
1-4 |
1-4 |
1-4 |
1-4 |
1-4 |
Power(kw) |
2×0.75 |
2×1.5 |
2×1.9 |
2×2.2 |
2×3.0 |
Product shows:
