Precision Control Ultrasonic Plastic Welding Machine Compare With Bransons Type
- Shanghai
- T/T PayPal Other Cash
You May Like
-
2000W Ultrasonic Plastic Welding Machine , Hf Plastic Welder Assembly Systems
-
20Khz 2000W Integrated Ultrasonic Plastic Welder With Dynamic Triggering Feature
-
Heavy Duty Ultrasonic Plastic Welding Machine For Automotive Industry / Auto Lamps
-
Integrated Ultrasonic Plastic Welder for Electronic Sealing Box , 20 khz 2000w
-
20KHz Ultrasonic Plastic Welding Machine For Electron / Stationery Packing
-
Durable 20 KHz Ultrasonic Plastic Welder Assembly System For Medical Industry
Product Details
| Brand Name | RPS-sonic | Place of Origin | China | |
| Model Number | RPS-W20 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Weight | 110KG | Voltage | 220V/110V | |
| Power | 2000W | Usage | ultrasonic plastic welder | |
| Frequency | 20KHZ | Dimensions | 70*40*120cm | |
| Welding Area | customization |
Product Description
Ultrasonic welding equipment can be easily customized to fit the exact specifications of the parts being welded. The parts are sandwiched between a fixed shaped nest (anvil) and a sonotrode (horn) connected to a transducer, and a ~20 kHz low-amplitude acoustic vibration is emitted. (Note: Common frequencies used in ultrasonic welding of thermoplastics are 15 kHz, 20 kHz, 30 kHz, 35 kHz, 40 kHz and 70 kHz). When welding plastics, the interface of the two parts is specially designed to concentrate the melting process. One of the materials usually has a spiked energy director which contacts the second plastic part. The ultrasonic energy melts the point contact between the parts, creating a joint. This process is a good automated alternative to glue, screws or snap-fit designs. It is typically used with small parts (e.g. cell phones, consumer electronics, disposable medical tools, toys, etc.) but it can be used on parts as large as a small automotive instrument cluster.
| Item No | RPS-W20 |
| Frequency | 20Khz |
| Power | 2000W |
| Voltage | 200-240V, Alternating current |
| 50-60hz, Single phase | |
| Electric current | 10A |
| Range of welding time | 0.05-10/sec |
| Environment Temperature | 5-50℃ |
| Air supply requirements | Clean dry compressed air, maximum pressure 7kg |
| Maximum pressure | 1.96KN |
| Maximum stroke | 100MM |
| Beats | 80CPM |
| Operated mode | Time mode or Energy mode |
| Weight | 110Kgs |
Applicable to ABS, PC, PE, PP, PS, PVC, SAM, acrylic, cellulose, nylon, etc.Widely used in automotive industry, electronic industry, medical industry, household appliances industry, no cloth clothing, office supplies, packaging industry, toy industry.
