Three Phase Smart Meter Test Bench

Three Phase Smart Meter Test Bench thumbnail-1
Three Phase Smart Meter Test Bench thumbnail-2
Three Phase Smart Meter Test Bench photo-1
Three Phase Smart Meter Test Bench photo-2
US$ 15000 - 39000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
SHENGDI
Place of Origin:
China
Model Number:
HS-6303E
Contact Supplier Request Quote Chat Now
Haiyan Shengdi Electrical Technical Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name SHENGDI
Place of Origin China
Model Number HS-6303E
Power Electronic
Usage Auto Testing Machine
Technical Specification:
1) The test bench accuracy class: 0.05/0.1
2) Reference standard energy meter:
   Three Phase Reference Standard Meter current range:0~120A;
   Accuracy class: 0.05 /0.1
3) Voltage amplifier:
   Output voltage range: 0-300V(phase-neutral);
   Output maximum power: 800VA
   Resolution: 0.01%;
   Stability: better than 0.05%/3 min(time base 5S);
   Distortion factor:
   Frequency range: 45Hz~65Hz;
   Power efficiency: more than 85%;
  Ambient temperature:10℃~50℃
 Electronic overload and short-circuit protection.
4) Current amplifier:
Output current: range: 1mA~120A
Output maximum power: 1500VA
Resolution: 0.01%;
Stability: better than 0.05%/3 min(time base 5S);
Distortion factor:
Frequency range: 45Hz~65Hz;
Power efficiency: greater than 85%;
Ambient temperature:10℃~50℃
Electronic overload protection and security for open current circuit.
5) Phase Angle: 0°~360° , resolution of phase angle setting: 0.1°;
6) Output frequency range: 45Hz~65Hz; resolution: 0.01Hz
7) Harmonic wave output: 2-21 sub-harmonic wave contents≤40%
Phase angle control (odd sub-harmonic wave)
Wave group control (sub-harmonic wave)
8) Output stability of power:
9) Numbers of calibrated energy meter: 6/8/12/16/20/24/32 on requested
10) Input power: 3×220V/380V (Y)+/-15%, 50/60Hz; Max. power consumption: 6000VA


Product Tags: Three Phase Energy Meter , Meter Test Station , Close-link Meter Test
