Scaffolding Walk Board Plank Sheet Production Line
Main Devices
Manual Decoiler x 1 unit
Main Roll Forming Machine x 1 unit
Cutter Device x 1 unit
PLC Control System x 1 unit
Hydraulic Pump x 1 unit
Technical Parameter
Feeding Material: Q235, Galvanized Steel Plate Sheet
Feeding Thickness: 0.8-1.5mm
Effective Width: 210mm/240mm
Forming Speed: 6-10m/min
Forming Stations: 20 stations
Shaft Diameter: 60mm
Roller Material: GCr15 steel with heat treatment, black treatment
Main Shafts Material: 40Cr steel with tempering treatment
Cutter Material: GCr12 steel with quenching treatment, HRC60-62°
Control System: PLC Control with Touch Screen
Main Motor Power: 11KW
Customized
We can customize forming machine for making special shape steel pipe/profile/frame/tile sheet. Please send the required formed profile specification for our best quote!
After-Sale Service
1.Warranty Period: 12 months. We offer replacement parts to clients free of charge during the period.
2.We offer technical support for entire life.
3.We can send our technicians to install and train the workers in the clients’ factories (extra fee required).
Packing Method
Main machine is naked and covered by plastic film
Term of Trade
Minimum Order Quantity (MOQ): 1 set
Delivery Time: about 30-45 working days
Port of Loading: Port of Xiamen
Payment Term: T/T
