12v 24v High Efficiency Brushless DC Pump Under-sink Filtered Hot Water Pump

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A Credit Card PayPal Other

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TOPSFLO	Place of Origin	China
Model Number	TL-B03	Application	Other, Under-sink filtered Hot Water pump
Power	Electric	Usage	Water
Standard or Nonstandard	Standard	Pressure	High Pressure

Product Description

TOPSFLO High Temperature Brushless DC Food grade Pump kichen under sink instant Hot water drink water pump

Product Description

Application:

Instant filtered boiling ,Chilled and sparkling water systems

Instant filtered drinking water systems

Coffee maker/coffee machine, Water cooler/water dispenser, Beverage dispenser

Water purifier/water dispenser, Tea maker, Milk dispenser, Laboratory

Medical treatment, Fountain, aquariums,Computer CPU cooling circulation,Water heating mattress

Product Features:

•.High efficiency brushless DC motor with long lifetime 20,000hours
•.Heavy duty work,can sustain continuous 24hours work
•.Special designed high efficiency closed-impeller for low power consumption
•.Motor widely voltage designed suitable for battery,Power supplying with peak-low voltage damply
•.All wetted materials Food grade approved to be safety usage
•.Durable permanent magnetic rotor/impeller and fine ceramic shaft
•.Low or no maintenance
•.IP protection level: IP68
•.Blocked protection

Product Specification:

Model	Product Code	Max Water Flow (L/Min)	Rated Voltage(DC)	Rated Current (A)	Max Water Head(M)	Rated Power(W)
B03	TL-B03-A12-0602	6.5	12	0.43	2.5	5.16
	TL-B03-A24-0602	6	24	0.22	2	5.28
	Customization: 1. /S Submersible, liquid ≤50°C 2. /FG (RPM) signal wire 3. /PWM or /5V speed control

Product Characteristics:

Max Flow Rate	6.5L/MIN
Max Water Head	2.5 M
Rated Voltage	12V/24V
Working Voltage Range	6V-18V /12V-28V
Motor Type	Brushless DC motor
Liquid Temperature	-40-105°C
Noise Class form 0.3M	37dB /Max
Ideal Life Time	20000 Hours
Working Mode	Continuous
OD of Inlet/Outlet	14 mm/9.4mm
Max pressure / Continue work Pressure	1.8Mpa / 0.5Mpa
Working liquid	Pure Water,antifreeze,etc
Power Supply	DC power supply, battery
Remarks	Can’t dry-running, not Self-priming

Usage Note:
Dry-running is prohibited.
Reverse polarity is not allowed (except customized).
The pump if dropped or with heavy vibration do not use.
Liquid contain impurities or magnetic particles are not allowed.
Liquid temperature over 80°C is not allowed (except high temperature models).
Acidic or alkaline liquid is prohibited (except customized).

Get more Technical data, please click here
