Help CenterJRC JMA-9172-SA SOLID STATE RADAR
Related Products
Features:
JRC's new IMO approved JMA-9172-SA, S-band Solid State radar, represents a new generation of marine radars, utilizing advanced signal processing technology to display targets with high accuracy while using a stabilized high-power solid state transceiver. The advanced radar functions and operation are based on JRC's successful JMA-9100 radar series.
Advanced signal processing
JRC's new solid state architecture integrates an advanced signal processing technology that detects and displays information at a new level.
These dedicated signal processing circuits are producing higher capability than a magnetron radar, and greatly exceeding detection performance.
The solid state has a (peak) power of 250 W, superseding a typical marine radar in which the magnetron has a 30kW power output.
Moving target detection
This solid state radar will easily detect moving targets in clutter compared to conventional radars. A new Doppler filter at the heart of the solid state radar not only detects moving targets in clutter, but also determines and clearly displays them on the screen.
Long range target detection
Advanced pulse compression with the 250 W solid state transceiver not only improves short range performance, but dramatically improves long range target detection while using only 1/100 of the power of a conventional radar.
Low maintenance transceiver
The radar integrates a highly reliable solid state transceiver in place of a life limited magnetron. The solid state radar provides higher reliability and performance and will keep maintenance costs to a minimum.
No tuning and pre-heating
The transceiver, by virtue of its solid state design, requires no tuning and pre-heating. Transmission is available immediately after the power is turned on.
Please send email to us for more details:
sales@malinsmarine.com
Product introduction
Malins Marine Service Co.,Ltd.
Was established in 2010 as a wholesaler and service provider of marine navigation & communication equipment.During the past years, the company has expanded by several folds in terms of size as well as business turnover.
The company started up in 2010 with one office and two persons and now has three offices and one warehouse, with working team of over 20 persons.As China continues to develop, Malins Marine is in a strong position not only to utilize the resources available domestically but also to introduce foreign shipyards and marine prodcuts to the ship owners and ship managers of China. Malins Marine collaborates closely with worldwide leading and specialized maritime equipment suppliers and manufacturers in order to provide our wide range of clients a full breadth of products and genuine spare parts as well.
With the support of a global network of well-known manufacturers, we are able to meet the growing & challenging demands of our customers from a sustainable development perspective.One-stop service for spare parts supplied and service, provide economic solution for ship owners & managers. To fully meet our customers’ requirements, we also specialise in navigation and communication systems, statutory annual radio surveys, annual performance tests as well as after-sales services. Our comprehensive line includes high quality electronics for navigation, communications, and safety & security applications. Over the years, we have built our service net covered China Coastal Port from north to south. Most of attending engineer trained by major makers and we owned genuine spare parts of kinds of makers in Shanghai head office.
Sales & Service
Sales navigation & communication equipment & spare parts
Service: installation/commission/repairing/calibration
Furuno, JRC, Sailor (Thrane&Thrane)- Cobham, Yokogawa, Tokimec (Tokyo Keiki), Raytheon Anschutz, Sperry, SAM Electronics, L3, Kelvin-Hughes, Mcmurdo, Jotron, Danelec, Samyung, Highlander, Headway, Rutter, Netwave, Simrad, JMC, Taiyo, STN Atlas, Cassens & Plath, C-plath, Teledyne, Consilium, Kongsberg, Samsung....
One-Stop Solutions, We care.
Email: sales@malinsmarine.com
Send Inquiry to This Supplier
