W3xH3 55inches (3640x2052mm) Interactive video walls with 3.5mm bezel are the hot choice by integrators. On the 3x3 55" LCD wall, we customized infrared touch solution. We make the interactive video wall hardware powerful enough to handle the advertisement, apps that controllers want to choose or change at any time, just through easy clicking on infrared interactive video wall. Meanwhile, the interactive video wall features advanced, it transforms viewers experience advertisement, they join in, they chose, and better understand the things you want to transfer.
Display Panel Specification | |
Panel Module Size |
55'' |
Backlight Type |
WLED |
Bezel |
3.5mm (1.8mm, 5.5mm optional) |
Aspect Ratio |
16:9 |
Response Time |
8ms (tyP.) |
Optimum Resolution |
1920(H)×1080(V) |
Viewing Angle |
178°/178° |
Display Colour |
16.7m |
On-Sreen Display language |
English, French,German, Italian, Polish, Russian, Spanish, Turkish,Simplified Chinese, Traditional Chinese, Arabic,Japanese |
Contrast Ratio (typical) |
4000:1 (tyP.) |
Brightness |
500cd/m ²(tyP.) |
Input Interface |
DVI*1、VGA*1、HDMI*1、VIDEO*1、RS232 *1 |
Control Interface |
DEBUG ISR/IR |
Other Interface |
RJ45 |
Input Voltage |
100V-240V,50-60Hz |
Rated Power |
220W |
Suitable Working Temperature |
0°C-50°C |
Suitable Storage Temperature |
-20°C-60°C |
Working Humidity |
10%-85%RH Non-Condensing |
Storage Humidity |
5%-95%RH Non-Condensing |
Accessories |
1pcs power cable（1.8m), 1pcs web cable（2m), 1pcs quality inspection certificate, I pcs manual instruction |
Touch Sensor Specification | |
Sensor Type |
Infrared |
Size |
3Wx3H 55'' (3640x2052mm) |
Available Touch Point |
Max. 2-32 points simultaneous |
Driver |
Driver-free |
Touch Input Method |
Pen, Finger, Finger of gloved hand Activation |
Response Time |
First click |
Interface |
USB 2.0 (full speed) |
Ambient Light |
Operating normally with sunlight below 100k lux(with patent and test report) |
Available Object Size for Touch |
Multi-touch: Min. Φ6mm, Single-touch: Min. Φ3mm |
Operation System |
Windows 8/7/XP, MAC OS X, Linux, Android |
Operation Voltage |
DC 4.75 to 5.25V |
Power Consumption |
|
Ambient Temperature |
Operating -20℃~60℃ |
Storage -40℃~85℃ | |
Humidity |
10%~90%RH |
