UNS N06625 The precipitation hardening nickel-chromium alloy containing niobium and molybdenum has high strength, good toughness, and corrosion resistance in high and low temperature environment at 700°C. The delivery state can be solution treatment or precipitation hardening.
Chemical Component%:
| Si | C | Ni | Nb | Cr | Mo | Ti | Co |
| ≤3.3 | ≤0.35 | 50~55 | 0.6~4.75 | 17~21 | 2.8~3.3 | 0.7~5.5 | ≤0.8 |
Mechanical Property:
| Tensile Strength | Yeild Point | Elongation | Hardness |
δb MPa |
δ0.2 Mpa |
δ10 % |
HB |
| ≥ 560 | ≥ 495 | ≥ 6 | 36 |
Product Name |
Nickel Alloy Pipe |
Material |
Nickel Alloy Pipe, Inconel625, Alloy 625, Nickel 625, Chornin625 |
Pipe Length |
Single Random Length and double Random Length. SRL:3M-5.8M DRL:10-11.8M or As clients requested length |
Size |
Size 1/4" to 24" Outside Diameter 13.7 mm to 609.6 mm |
Wall thickness |
SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS |
Standard |
ASTM B165 , ASTM B163 , ASTM B829 , ASTM B775 ,ASTM B725 ,ASTM B730 , ASTM B751 ASTM B 444, ASME SB444, |
Applications field |
The elevated temperature strength, excellent corrosion resistance and work ability at 700℃ properties made it use in a wide range of high requirement environments. |
Chemical composition |
Ni: 50~55% ; Cr:17~21% ; Fe: balance;Mo:2.8~3.3% ; Nb: 4.75~5.5% ; Co: ≤1.0% ; C≤0.08% ; Mn≤0.35% ; Si≤ 0.35% ; Cu≤0.3% ; Al: 0.2~0.8% ; Ti: 0.65~1.15% ; P≤0.015% ; |
Certificate |
ISO/PED/TUV/SGS/LR/BV |
Main Market |
Asia, Middle East, Europe, America, Africa, Australia, etc |
