TS 2.5/3/3.33/5 Taxi Top Display Taxi Topper LED Display Taxi LED Display Powered Taxi Roof LED Display Exporter
You May Like
-
FC Series FC 2.5/4 Flexible LED Display Flexible Shape LED Poster China Flexible LED Display
-
PT LED Poster Series Digital LED Poster Advertising LED Poster China LED Poster Smart Advertising Led Poster
-
VA Series LED Arrow Board Portable LED Sign Supplier
-
TS 2.5/3/3.33/5 Taxi Top LED Display Taxi Roof LED Display Exporter Taxi LED Display China
-
TW P2.8 / P3.91 Transparent Car Rear Window LED Display Car Window Led Display Portable LED Sign China
-
Digital LED Poster Display Screen For Exhibition Meeting LED Poster
Product Details
| Brand Name | NSELED | Place of Origin | China |
Product Description
TS 2.5/3/3.33/5 Taxi Top Display Taxi Topper LED Display Taxi LED Display powered Taxi Roof LED Display Exporter
High Resolution TAXI LED DISPLAY.
2.5 mm, 5000 nit
3.0 mm, 3500 nit
3.33mm, 4500 nit
5.0 mm, 5500 nit
The third edition of our Taxi LED Display
adopts high brightness and lower consumption
SMD LEDs to get the best display performance.
It will turn to be a new outdoor
advertisement method featuring in low cost and high effectiveness.
Features
High Brightness.
Taxi TOP LED display enable to reach 6500nit by using high intesity outdoor LEDs to make sure brighter and clear enough under the direct sunlight.
undefined
Safe, Reliable and Stable
Taxi LED display panel tested under the temperature 70℃ and 80% humidity for 96 hours.
Whole display tested at 70℃ for 24 hours.
100% vibration Testing.
Taxi Roof LED display has many advantages:
Easy installation and maintenance
Easy SD-Card installation
Easy installation with Card Bracket
Easy replacement of module& power supply
Smart Asynchornous Control
Group Intelligent Control(GIC System)
Location Precise Advertising
Advertising Management System
3G/4G/WIFI/USB control
GPS real-time monitoring
Taxi LED Display with Intelligent Design on Power & Heat dissipation
Lower Power Consumption of whole sign, which enable to be running on any car embedded battery system.
Intelligent Power Supply Management.
Good Ventilation by using high speed & ball-bearing Fan.
Rapid Technical Support on Software and Hardware
Online technical support
Installation Trainning Courses
Customized design available
Hight Resolution Space Available
Taxi Roof LED display with P2.5mm High Resolution
3D Performance with Hard Decoding Technology
Taxi Top LED Display with Optional MultiFuctional Integrated System
Lighting & Temperature Sensor Integrated
Optional Camera System
Taxi top LED Screen Specification
Product name: | P2 | P2.5 | P3 | P3.33 | P5 |
Model Type: | TS2 | TS2.5VF | TS3OT | TS3.33 | TS59632 |
Pixel Pitch | 2mm | 2.5 mm | 3mm | 3.33 mm | 5mm |
LED Type | SMD 1921 | SMD2121 | SMD2020 | SMD 1921 | SMD 2727 |
Pixel Density | 250,000 dot/ m2 | 160,000 dot/ m2 | 111,111 dots | 90,000 dot/ m2 | 40000 dot/ m2 |
Module Size | 320*160mm | 160*160mm | 192*96mm | 320*160mm | 160*160mm |
Screen Size | 960mm*320mm | 960mm*320mm | 768*288mm | 960mm*320mm | 960mm*320mm |
Screen Resolution | 480*160 dot | 384*128 dot | 192*96mm | 288*96 dot | 192*64 dot |
Frame Size | 1100mm( L) x 410mm(H) XW:164mm(bottom)/ 99mm (top) | 1100mm( L) x 410mm(H) XW:164mm(bottom)/ 99mm (top) | 820mm( L) x 390mm(H) X W:170mm(bottom)/ 99mm (top) | 1100mm( L) x 410mm(H) XW:164mm(bottom)/ 99mm (top) | 1100mm( L) x 410mm(H) XW:164mm(bottom)/ 99mm (top) |
Brightness | 4500 nit | 4500 nit | 4000 nit | 4500 nit | 5500 nit |
Contrast | 8000:01:00 | 8000:01:00 | 8000:01:00 | 8000:01:00 | 8000:01:00 |
View Angle | 150°(H)/150°(V) | 150°(H)/150°(V) | 150°(H)/150°(V) | 150°(H)/150°(V) | 150°(H)/150°(V) |
Scan Mode | 1/32 scan | 1/32 scan | 1/16 scan | 1/24 scan | 1/8 scan |
Power Supply Input | DC9--24V | DC9--24V | DC9--24V | DC9--24V | DC9--24V |
Max Consumption | 450w | 430w | 250w | 400w | 450w |
Average Consumption | 130w | 120w | 80w | 120w | 150w |
Refresh Rate(Hz): | 1920Hz / 3840 Hz(Optional) | 1920Hz / 3840 Hz(Optional) | 1920Hz | 1920Hz | 1920Hz |
Optimal Viewing Distance | 1--20M | 1--20M | 3--50M | 1--20M | 3--50M |
Life Span | 100,000 Hours | 100,000 Hours | 100,000 Hours | 100,000 Hours | 100,000 Hours |
MTBF | 10,000 Hours | 10,000 Hours | 10,000 Hours | 10,000 Hours | 10,000 Hours |
Control Method | Asychronous | Asychronous | Asychronous | Asychronous | Asychronous |
Control Mode | 3G/4G/WIFI/ Ethenet/ USB | 3G/4G/WIFI/ Ethenet/ USB | 3G/4G/WIFI/ Ethenet/ USB | 3G/4G/WIFI/ Ethenet/ USB | 3G/4G/WIFI/ Ethenet/ USB |
Temperature Operating | -40°～+75° | -40°～+75° | -40°～+75° | -40°～+75° | -40°～+75° |
Working Humidity | 10%–90%RH | 10%–90%RH | 10%–90%RH | 10%–90%RH | 10%–90%RH |
Protection Rating: | IP65 | IP65 | IP65 | IP65 | IP65 |
Power Protection | over-temperature/over-current/ | over-temperature/over-current/ | over-temperature/over-current/ | over-temperature/over-current/ | over-temperature/over-current/ |
over-voltage protection | over-voltage protection | over-voltage protection | over-voltage protection | over-voltage protection | |
Screen Weight | 23 kg | 23 kg | 15kg | 23 kg | 23 kg |
Package Dimension | 1100mm(L) X 500mm(H) X 270mm(W) | 1100mm(L) X 500mm(H) X 270mm(W) | 960mm(L) X 430mm(H) X 210mm(W) | 1100mm(L) X 500mm(H) X 270mm(W) | 1100mm(L) X 500mm(H) X 270mm(W) |
Gross Weight: | 28 kg | 28 kg | 20kg | 28 kg | 28 kg |
Certificates | CE./ROHS/FCC | CE./ROHS/FCC | CE/ ROHS/FCC | CE./ROHS/FCC | CE/ROHS/FCC |
NSE supply the portable LED sign, LED traffic display, which include taxi top LED display, bus LED display, LED arrow board, variable message sign(VMS), VMS trailer display,etc
