Product Description
P/N: Push plunger type Limit Switch
Model No.: RL8107
Features
Compact design,
Easy wiring with full-open terminals
Dust proof, water proof and oil resistant construction
1. EN60947-5-1(GB14048.5) performance
Item | Rating |
Rated insulation voltage (Ui) | 250VAC |
Rated shock resistance voltage(Uimp) | 2.5KV |
Switching overvoltage | 2.5KV |
Rated enclose thermal current(Ithe) | 5A |
Conditional short circuit current | 100A |
Short circuit protection device | 10A fuse |
Protective construction | IP64 |
Pollution degree | 3 |
Operating characteristics
Item | Characteristics |
OF max. | 0.88N {90gf} |
RF min | - |
PT.max (mm) | 30 |
MD.max(mm) | - |
OT.min(mm) | 20 |
TT.(mm) | 50 |
Rated value and characteristics
Rated working current | 5A 125,250VAC; 0.4A 125VDC(..) | ||
Contact type | Contact resistance (initial value ) | Under 15 mΩ (no include copper resistance ) | |
Contact material | Sliver cadmium oxide contact(if no need cadmium,[according with ROSH certificate ] can customize | ||
Electrical | Insulation resistance (initial value) | 100 mΩ min. (use the DC500V insulation resistance test) | |
Dielectric strength | Between Non-continuous terminals (initial value): 1500V 50/60HZ for 1 min Between non voltage metal parts and each terminal: 2000V 50/60HZ for 1min Between ground and each terminal: 2000V 50HZ for 1 min
| ||
Mechanical | Shock resistance | In the free position | Less than 98m/s2(10G) |
In the full operating position | Less than 294m./s2(30G) | ||
Vibration resistance | 1.5mm double amplitude 10-55HZ | ||
Expected Life | Mechanical | 10,000,000 operations min. (on/off frequency 120 operations/min) | |
Electrical | 300,000 operations min. (rated load ), electromagnetism contactor FC-100(AC200V) load ; 5,000,000 operations min. | ||
Using condition | Ambient temperature /Ambient humidity | -20~+60 95%RH max. (at +5~20) | |
The max on/off frequency | 120 operations/min | ||
