Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge

Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge thumbnail-1
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge thumbnail-2
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge thumbnail-3
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge thumbnail-4
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge thumbnail-5
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge photo-1
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge photo-2
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge photo-3
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge photo-4
Affordable Low Weight Perforated Cable Tray Sizes Steel Cable Tray Bridge photo-5
Negotiable MOQ: 1 Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Shandong Huaxian
Place of Origin:
China
Material:
Steel
Contact Supplier Request Quote Chat Now
Shandong Huaxian Electric Technology Co.,Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao ,Shanghai
Delivery Detail:
10 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Shandong Huaxian
Place of Origin China
Material Steel
Length Max 6000mm
Type Ventilated or Perforated Trough
Width Max 1000mm
Max. Working Load depends on the size
Side Rail Height 50-200mm

1. Product Inforamtion :



Finishes&materials:

HDG, Pre-galvanized, Electronic-galvabized, Powder-coating, stainless steel 304/316, GI


Length: Maximum 3000mm perforated cable tray



Specification :


perforated cable tray dimension&weight(kg/meter)
W*H/Thick
0.8 1 1.2 1.5 2 2.5
50*50 Lid  0.53 0.66 0.79 0.99 1.32 1.65
Tray 1.17 1.48 1.78 2.23 2.97 3.71
75*50 Lid  0.69 0.87 1.04 1.3 1.73 2.16
Tray 1.35 1.69 2.03 2.54 3.38 4.23
100*50 Lid  0.86 1.07 1.29 1.61 2.14 2.68
Tray 1.52 1.9 2.28 2.84 3.79 4.74
150*50 Lid 1.19 1.48 1.78 2.23 2.97 3.71
Tray 1.85 2.31 2.77 3.46 4.62 5.77
200*50 Lid  1.52 1.9 2.27 2.84 3.79 4.74
Tray 2.18 2.72 3.26 4.08 5.44 6.8
250*50 Lid  1.85 2.31 2.77 3.46 4.62 5.77
Tray 2.5 3.13 3.76 4.7 6.26 7.83
300*50 Lid 2.18 2.72 3.26 4.08 5.44 6.8
Tray 2.84 3.54 4.25 5.32 7.09 8.86
350*50 Lid 2.51 3.13 3.76 4.7 6.26 7.83
Tray 1.98 3.96 4.75 5.93 7.91 9.89
400*50 Lid
3.54 4.25 5.32 7.09 8.86
Tray
4.37 5.24 6.55 8.74 10.92
450*50 Lid
3.96 4.75 5.93 7.91 9.89
Trya
4.78 5.74 7.17 9.56 11.95
500*50 Lid
4.37 5.24 6.55 8.73 10.92
Tray
5.19 6.23 7.79 10.39 12.98
550*50 Lid
4.78 5.73 7.17 9.56 11.95
Tray
5.61 6.73 8.41 11.21 14.01
600*50 Lid
5.19 6.23 7.79 10.39 12.98
Tray
6.02 7.22 9.03 12.03 15.04
650*50 Lid
5.6 6.73 8.41 11.21 14.01
Tray
6.43 7.71 9.64 12.86 16.07
700*50 Lid
6.02 7.22 9.03 12.03 15.04
Trya
6.84 8.21 10.26 13.68 17.1
750*50 Lid
6.43 7.71 9.64 12.86 16.07
Trya
7.25 8.7 10.88 14.51 18.13
800*50 Lid
6.84 8.21 10.26 13.68 17.1
Tray
7.67 9.2 11.5 15.33 19.17
850*50 Lid
7.25 8.7 10.88 14.51 18.13
Tray
8.08 9.69 12.12 16.16 20.2
900*50 Lid
7.67 9.2 11.5 15.33 19.16
Tray
8.5 10.19 12.74 16.98 21.23

2.Product Pics:





Company Introduction:

Shandong Hua xian Electric Technology Company Limited is specializes in manufacturing energy-saving cable trays, channel type cable trays, ladder type , tray type and wire mesh cable trays, seismic support and hanger system, urban underground commom trench, busways, and full sets of high and low voltage equipment etc., the factory is located at No. 23 Zihe Avenue, Zhangdian ,Zibo, Shandong, China, and it covers an area of more than 4000 square meters and a construction area of 1600 square meters . The company is certified under ISO 9001:2015 Quality Management System, ISO14001 Enviromental Management System and OHSAS 18001:2007 Occupational Health and Safety Management System.

Since the establishment of the company,Hua xian introduces the most advanced production equipment , be strictly with qualified raw material and improve our  production technology,all these makes Huaxian played a leading role in the industry.

Welcome friends to visit our factory, and willing to have a great cooperation with you !

Product Tags: cable tray bridge,cable stand , Ventilated Cable Tray Supporting System,Galvanized Ventilated Cable Tray Supporting System , cable rack,cable bracket , Steel Strong cable tray , cable carrier bracket , Light Weight trough cable tray , energy saving cable tray
