Marine Watertight Type Clear View Screen with Heater

Standard Packing: Wooden Case,Carton or Pallet, etc. 1. If small dimension, it could fit in 20GP or 40GP container; 2. If large dimension, we recommend shipping by FCL or LCL Conatiner.

Marine Watertight Type Clear View Screen with Heater

Product Information

1. BOCHI ship clear view screen applies double layer glass structure for completely perventing rain and water from the external environment into the interior space with certain air tight property and better visual field under normal condition.
2. BOCHI ship clear view screen is suitable for various oil tankers,chemicals tankers and high speed naval ships.
4. BOCHI ship clear view screen can remove the rain, snow and sea water from the windows with the centrifugal force generated from the high speed rotation of glass drive with the motor which is installed in the center of main frame, and can keep clear vision.
5. BOCHI ship clear view screen is installed with elctronthermal ice smelling device and is applicabele for all-weather sailing.
6. BOCHI ship clear view screen complies with CB644-1992:Marine Clear View Screen.

Product Description

1.Power supply & voltage: AC 220V, AC 110V, DC 24V
2.Frequency:50Hz/60Hz
3.Input power: Motor power: ≤90W, Heater power: ≤ 250W
4.Protection grade: Outdoor part:IP56; Indoor Part: IP22
5.Thickness of mounting wall: 10~22mm (when requiring above 15mm, pls note this in your order)
6.Outling dimension of control box:
  Faceplate: 150*120mm
  Box: 130*100*132mm
7. This type marine clear view screen must use our control box which is attached for the window.

Product Drawing

Product Details

 Bochi Marine Group could disign and offer you best products with good servces: we take care of ur order!

1. Punctual delivery time:

• We put your order into our tight production schedule, keep our client informed about production process, ensure your punctual delivery time.
• Shipping notice/ insurance to you as soon as your order is shipped.

2. After sales service:

• After receive the goods, We accept ur feedback at first time.
• We could provide installation guide, if you have need, we could give you global service.
• Our Sales are 24-hours online for ur request

3. Professional sales:

• We value every inquiry sent to us, ensure quick competitive offer.
• We cooperate with customer to bid tenders. Provide all necessory docuement.
• We are a sales team, with all techinical support from engineer team.

Bochi Have many global clients, we offer professional service to them.  With the aim of "to establish a close strategic partnership and develop together with customers", we will work whole-heartedly to improve our products and service. We will also pledge to work jointly with business partners to elevate our cooperation to a higher level and share success together with our customers. We are looking forward to establishing relationships with you in the near future.

1. We are one of the manufacturers of marine equipments in China. Located in Chongqing, which is among the largest industrial and commerical cities in China.

2. We operate as the import and export branch of Chongqing BOCHI Machinery Group.

3. We are Alibaba Excellent Supplier & Alibaba Recommended Supplier!

4. With the aim of "to establish a close strategic partnership and develop together with customers", we will work whole-heartedly to improve our products and service .

Marine Equipments Certification

ISO Certificate

Bochi Products: High Quality Assurance

• Product Range: We are specialized in all marine equipments and technique solution, that means we could offer you all marine equipments and accessories.
• Product Design: We have big strong engineer team, for all marine products, we will design drawings according to ur requirements, or check the drawings you give us, all productions must be start after drawings confirmation.
• Product Process: all product flow are finished in our manufacture bases, so the quality and delivery time could keep the same good, also avoid some details mistake.
• Product Inspection: We have ISO certificate, and general products, we will provide Mill Certificate, also, we could provide ABS, BV, CCS, DNV, GL, LR, KR, NK, RINA, RS certificate, and we accept third party inspection, such as SGS etc. our clients also could come to visit our factory.

Any Inquiry or Questions, Pls Kindly Contact Us!
