Home > Products > Marine Piping & Valve System > Carbon Steel Butt Weld 90 Degree Pipe Elbow Fittings
Carbon Steel Butt Weld 90 Degree Pipe Elbow Fittings
- Chongqing Shanghai Shenzhen Qingdao etc.
- T/T Credit Card
You May Like
Product Details
| Brand Name | BOCHI | Place of Origin | Chongqing, China | |
| Model Number | BMMVPTEEL | Material | Carbon Steel | |
| Shape | Equal | |||
| Technics | Forged | Connection | Welding | |
Weld Elbow:Wooden case, pallet or as customer's requirement
Product Description
Carbon Steel Butt Weld 90 Degree Pipe Elbow Fittings
Brief Introductions
· BOCHI is one of the suppliers of marine equipments in China. Located in Chongqing, which is among the largest industrial and commerical cities in China.
· We are Alibaba Excellent Supplier & Alibaba Recommended Supplier!
· We can supply the different kinds of products about marine auxiliary marchinery, like pumps, valves, compressors, boilers, oil separators, fans, marine sewage treatment system etc. and also others spare parts.
Products Data
| Model | Nominal Diameter | Outside Diameter at Bevel | Center to End | |||
| 90°Elbow | ||||||
| A | ||||||
| DN | NPS | Series A | Series B | Long Radius | Short Radius | |
| BMMVPTEEL001 | 15 | 0.5 | 21.3 | 18 | 38 | - |
| BMMVPTEEL002 | 20 | 0.75 | 26.9 | 25 | 38 | - |
| BMMVPTEEL003 | 25 | 1 | 33.7 | 32 | 38 | 25 |
| BMMVPTEEL004 | 32 | 1.1/4 | 42.4 | 38 | 48 | 32 |
| BMMVPTEEL005 | 40 | 1.1/2 | 48.3 | 45 | 57 | 38 |
| BMMVPTEEL006 | 50 | 2 | 60.3 | 57 | 76 | 51 |
| BMMVPTEEL007 | 65 | 2.1/2 | 76.1(73) | 76 | 95 | 64 |
| BMMVPTEEL008 | 80 | 3 | 88.9 | 89 | 114 | 76 |
| BMMVPTEEL009 | 90 | 3.1/2 | 101.6 | - | 133 | 89 |
| BMMVPTEEL010 | 100 | 4 | 114.3 | 108 | 152 | 102 |
| BMMVPTEEL011 | 125 | 5 | 139.7 | 133 | 190 | 127 |
| BMMVPTEEL012 | 150 | 6 | 168.3 | 159 | 229 | 152 |
| BMMVPTEEL013 | 200 | 8 | 219.1 | 219 | 305 | 203 |
| BMMVPTEEL014 | 250 | 10 | 273 | 273 | 381 | 254 |
| BMMVPTEEL015 | 300 | 12 | 323.9 | 325 | 457 | 305 |
| BMMVPTEEL016 | 350 | 14 | 355.6 | 377 | 533 | 356 |
| BMMVPTEEL017 | 400 | 16 | 406.4 | 426 | 610 | 406 |
| BMMVPTEEL018 | 450 | 18 | 457.2 | 478 | 686 | 457 |
| BMMVPTEEL019 | 500 | 20 | 508 | 529 | 762 | 508 |
| BMMVPTEEL020 | 550 | 22 | 559 | - | 838 | 559 |
| BMMVPTEEL021 | 600 | 24 | 610 | 630 | 914 | 610 |
| BMMVPTEEL022 | 650 | 26 | 660 | - | 991 | 660 |
| BMMVPTEEL023 | 700 | 28 | 711 | 720 | 1067 | 711 |
| BMMVPTEEL024 | 750 | 30 | 762 | - | 1143 | 762 |
| BMMVPTEEL025 | 800 | 32 | 813 | 820 | 1219 | 813 |
| BMMVPTEEL026 | 850 | 34 | 864 | - | 1295 | 864 |
| BMMVPTEEL027 | 900 | 36 | 914 | 920 | 1372 | 914 |
| BMMVPTEEL028 | 950 | 38 | 965 | - | 1448 | 965 |
| BMMVPTEEL029 | 1000 | 40 | 1016 | 1020 | 1524 | 1016 |
| BMMVPTEEL030 | 1050 | 42 | 1067 | - | 1600 | 1067 |
| BMMVPTEEL031 | 1100 | 44 | 1118 | 1120 | 1676 | 1118 |
| BMMVPTEEL032 | 1150 | 46 | 1168 | - | 1753 | 1168 |
| BMMVPTEEL033 | 1200 | 48 | 1220 | 1220 | 1829 | 1219 |
Products Pictures
Bochi Corporation could disign and offer you best products with good servces: we take care of our order!
We are one of the manufacturers of marine equipments in China. Located in Chongqing, which is among the largest industrial and commerical cities in China.
We are Alibaba Excellent Supplier & Alibaba Recommended Supplier!
With the aim of "to establish a close strategic partnership and develop together with customers", we will work whole-heartedly to improve our products and service.
Our good quality and best service will make you satisfied.
If u are interested in our product,pls feel free to contact me ! We will give u the competitive quotation!
