Degree 45 Copper Elbow of Pipe Fitting
- 5000 Piece / Pieces per Month
- Shanghai Chongqing Shenzhen Qingdao etc.
- T/T Credit Card
You May Like
Product Details
| Brand Name | BOCHI | Place of Origin | China | |
| Model Number | BMMVPTEEC | Type | Elbow | |
| Shape | Equal | Technics | Casting | |
| Connection | Welding |
Copper elbow:Fittings are put into plastic bags with carton box packing.As customer required.
Product Description
Degree 45 Copper Elbow of Pipe Fitting
DN | Dw | Structure dimension | Weight(kg) | |||||
elbow 45° | elbow 90° | |||||||
l1(mm) | L2(mm) | L3(mm) | PN 1.0 MPA | PN 1.6 MPA | PN 1.0 MPA | PN 1.6 MPA | ||
6 | 8 | 12 | 7 | 14 | 0.01 | 0.01 | ||
8 | 10 | 13 | 15 | |||||
10 | 12 | 15 | 9 | 19 | ||||
15 | 16 | 19 | 11 | 24 | 0.02 | 0.02 | ||
20 | 13 | 32 | 0.03 | 0.03 | ||||
20 | 25 | 26 | 15 | 38 | ||||
25 | 30 | 30 | 16 | 42 | ||||
32 | 38 | 35 | 18 | 51 | 0.09 | 0.09 | ||
40 | 45 | 43 | 22 | 60 | 0.14 | 0.21 | 0.14 | 0.21 |
50 | 55 | 51 | 25 | 72 | 0.23 | 0.33 | 0.21 | 0.31 |
65 | 70 | 61 | 28 | 86 | 0.34 | 0.52 | 0.48 | 0.64 |
80 | 85 | 69 | 30 | 100 | 0.51 | 0.86 | 0.67 | 1.09 |
100 | 105 | 76 | 32 | 109 | 0.91 | 1.26 | 1.26 | 1.87 |
108 | 0.76 | 1.12 | 1.12 | 1.66 | ||||
125 | 133 | 95 | 36 | 133 | 1.76 | 2.57 | 2.57 | 4.12 |
150 | 159 | 112 | 42 | 158 | 2.43 | 4.26 | 4.26 | 6.22 |
200 | 219 | 141 | 45 | 204 | 5.52 | 9.89 | 10.99 | 14.72 |
Pipe fitting is important equipment for marine, Bochi Marine Group could disign and offer you best products with good servces: we take care of ur order!
1. We are one of the manufacturers of marine equipments in China. Located in Chongqing, which is among the largest industrial and commerical cities in China.
2. We operate as the import and export branch of Chongqing BOCHI Machinery Group.
3. We are Alibaba Excellent Supplier & Alibaba Recommended Supplier!
Q:What can you offer classification society certificate?
A: BOCHI can supply CCS, ABS, DNV, GL, LR, RINA, BV, NK, KR, RS...etc.
We can satisfy all the customers requirments.
Q: How long is your delivery time?
A: BOCHI delivery time usually is 15-20 days.
According to customer's order quantity.
Q: How about your products quality?
A: All products flow are our manufacture bases,so so we can guarantee the quality of our products.
We have a professional after-sales service, any questions about the product can tell us. We will give
you satisfied reply timely.
Any questions or unclear about the product,contact me please!
I must give your my sincerely answer in 24 hours!
