Removable Two Stage Compression Diesel Engine Screw Air Compressor

Bochi Corporation
5Yrs
Removable Two Stage Compression Diesel Engine Screw Air Compressor thumbnail-1
Removable Two Stage Compression Diesel Engine Screw Air Compressor thumbnail-2
Removable Two Stage Compression Diesel Engine Screw Air Compressor photo-1
Removable Two Stage Compression Diesel Engine Screw Air Compressor photo-2
US$ 11,350 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Bochi
Place of Origin:
China
Certification:
ISO
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Bochi
Place of Origin China
Certification ISO
Type Screw
Warranty 1 YEAR
Weight as per product
Dimension(L*W*H) as per product
Condition New
Voltage diesel engine
Mute No
Lubrication Style Lubricated
Power Source Diesel
Configuration Portable

Removable Two Stage Compression Diesel Engine Screw Air Compressor

Product Description

 Removable Two Stage Compression Diesel Engine Screw Air Compressor

1.  Discharge pressure:  0.7 -2.2 Mpa

2.  Air Delivery:  6.0-30 m3/min

3.  Diesel Engine Power:  58-298 KW

Model

Capacity
(m3/min)

Working

Pressure (Mpa)

Diesel Engine  (KW)

Dimension
(mm)

*LGCY-6/7

6

0.7

YCD4B22-95

3750×1920×1700

*LGCY-7.5/7

7.5

0.7

YC4D80-K20

3900×1920×1700

*LGCY-9/7

9

0.7

YC4D95Z-K20

3900×1920×1700

*LGCY-10/7

10

0.7

YC4D95Z-K20

3900×1920×1700

*LGCY-10/10

10

1

4BTA3.9-C125

3900×1920×1900

*LGCY-8.5/14

8.5

1.4

4BTA3.9-C125

3900×1920×1900

*LGCY-12/7

12

0.7

4BTA3.9-C125

3900×1980×1900

*LGCY-12/7A

12

0.7

YC4A125Z-T21

4000×1980×1900

*LGCY-9/14

9

1.4

YC6B150Z-K20

4080×1980×2350

*LGCY-10/13

10

1.3

YC6B150Z-K20

4080×1980×2350

*LGCY-12/10

12

1

YC6B150Z-K20

4080×1980×2350

*LGCY-12/10Q

12

1

QC6108ZG

4080×1980×2350

*LGCY-12/12

12

1.2

EQ6BT5.9-C160

4080×1980×2350

*LGCY-12/13

12

1.3

6BTA5.9-C180

4080×1980×2350

LGCY-13/13

13

1.3

6BTA5.9-C180

3450×1520×2220

LGCY-13/13A

13

1.3

YC6A180Z-T21

3450×1520×2220

LGCY-15/13

15

1.3

WD415.23

3380×1650×2500

LGCY-15/13A

15

1.3

YC6A240-20

3380×1650×2500

LGCY-17/7

17

0.7

6BTA5.9-C180

3380×1640×2350

LGCY-13/17

13

1.7

6CTA8.3-C215

3780×1980×2350

LGCY-16/13

16

1.3

6CTA8.3-C215

3980×1800×2450

LGCY-17/14.5

17

1.45

6CTA8.3-C260

3980×1800×2450

LGCY-18/17

18

1.7

6CTA8.3-C260

3980×1800×2450

LGCY-22/8

22

0.8

6CTA8.3-C260

4580×1950×2600

LGCY-22/14

22

1.4

YC6M340L-K20

4580×1950×2600

LGCY-22/14K

22

1.4

6LTAA8.9-C325

4580×1950×2600

LGCY-27/10

27

1

YC6M340L-K20

4600×1950×2850

LGCY-32/10

32

1

YC6M395L-K20

4600×1950×2850

KSCY-14/12

14

1.2

6BTA5.9-C180

3980×1800×2100

LGCY-19.5/19

19.5

1.9

6CTA8.3-C260

3980×1800×2650

LGCY-19.5/19A

19.5

1.9

YC6M260L-K20

3980×1800×2650

LGCY-22/20 Cummins

22

2

6LTAA8.9-C325

4600×1950×2850

LGCY-22/20 Yuchai

22

2

YC6M340L-K20

4600×1950×2850

LGCY-26/20 Cummins

26

2

6LTAA8.9-C360

4600×1950×2850

LGCY-27/20 Yuchai

27

2

YC6M395L-K20

4600×1950×2850

LGCY-27/22 Cummins

27

2.2

NTA855-P400

4600×1950×2850

LGCY-30/17 Yuchai

30

1.7

YC6M395L-K20

4600×1950×2850

LGCY-33/25 Cummins

33

2.5

QSZ13-C550

4700×2100×2850

LGCY-33/25 Yuchai

33

2.5

YC6K550L

4700×2100×2850

 Removable Two Stage Compression Diesel Engine Screw Air Compressor







Packaging & Shipping

Removable Two Stage Compression Diesel Engine Screw Air CompressorRemovable Two Stage Compression Diesel Engine Screw Air Compressor



Company Information

BOCHI Marine/Ship Equipment Department is a total solution provider with his head office in Bochi Corporation. We are able to provide value added services and qualified marine equipments.
