DMX512 Constant Voltage Decoder
- 1000 Piece / Pieces per Month
- China Port
- T/T Credit Card
Product Details
Brand Name: | BOCHI | Place of Origin: | Chongqing, China | Model Number: | BMM933 |
High Definition: | Yes |
Packaging Details
cartons
Product Description
Welcome to use BM-833 series DMX512 decoder & driver. PX series adopt the advanced micro-computer control technology and converted the DMX512/1990 digital signal widely used in international to the analog control signal. 1~3 channels output for option and each channel able to achieve 256 gradations of controling, and also it can be used as the connector of PC digital light controller and analog light modulator. It is mainly used for the controlling of buildings & lights applied LED.
Specifications
Input voltage | DC12V~DC24V |
Max load current | 3A/CH×3 |
Output Power | <216W(24V);<108W(12V) |
Output Scale level | 256 levels |
Input signal | DMX512/1990 |
Output signal | 3 constant voltage PWM |
Output DMX Channel | 3Chs or 4Chs (4th CH is shutter strobe) |
DMX512 socket | Standard XLR-3R |
|
Basic Features
1.Meets DMX512/1990
2.256-level brightness,full-color control
3.With 3 channels output and Max.3A/CH output
4.With control system,can express perfect effect
5.With the light color selected mechanism, and be able to control the light with 1~3 colors
6.an set the DMX address freely
7.Can be custom-made
Input and output interfaces can be interchanged for using
1, Address setting interface
How to use See "DMX series of addresses dial code table"
2, Addresses dial code table of DMX series
DC 12-24V input, supply power for decoder and the lamps it takes.
3 Driver output interface
Common anode,V+ and R,G,B interface,can drive kinds of RGB module or single-color module,
Can regulate output current according to the actual load.
remark:
Connect the anode and RGB wire of common anode RGB module to the output interface of decoder directly;
Connect the anode wire of single-color module to V+ on decoder, and connect the cathode wire to one of RGB pin
according to the LED's color; Connect several colors single-color module to one decoder, please connect their
anode wires to V+ pin on decoder.
BOCHI can supply CCS, ABS, DNV, GL, LR, RINA, BV, NK, KR, RS...etc.
We can satisfy all the customers requirments.
Classification society certificate
