90~120KW Six Cylinder Marine Diesel Engine

90~120KW Six Cylinder Marine Diesel Engine thumbnail-1
90~120KW Six Cylinder Marine Diesel Engine photo-1
US$ 6,000 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
2002
Annual Export Value:
US$5 Million - US$10 Million
Contact Supplier Request Quote Chat Now
Bochi Corporation
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us




Product Description



1.This series of  diesel engine are developed with German FEV



2.Cylinder head and boby are using alloy cast iron,high enhance degree,using integral shaft ,sliding bearing,small and light,high reliability



3.high-performance combustion chamber and Intake Swirl,fuel consumption indicator is far superior to the other same power products



4.using necking combuston technology,AD type high-pressure oil  pump;using proprietary piston ring sealing technique,the consumption of lubricate is much lower



5.Suitable for small boat , fishing boat main engine and 40~64kw auxiliary engine







6B Series
Model
Power/Speed
Intake way
Displacement
Net weight
Length*Width*Height
Flywheel
Encloser
Function
Continuous
One-hour
(L)
(Kkg)
(mm)
BMMPPDEY6108CA
63/1500
69.3/1500
Normally Aspirated
6.871
700
1252*780*1075
SAE 11.5
SAE 2
main engine/
auxiliary engine
BMMPPDEY6108CA1
82/2000
90.2/2065
Normally Aspirated
6.871
700
1252*780*1075
main engine
BMMPPDEY6108ZC
80/1500
88/1500
turbocharged
6.871
700
1293*780*1198
main engine/
auxiliary engine
BMMPPDEY6108ZCA
103/2300
113.3/2374
turbocharged
6.871
700
1293*780*1198
main engine
BMMPPDEY6108ZLCA
90/1500
99/1548
turbocharged
intercooled
6.871
750
1420*810*1020
main engine/
auxiliary engine
BMMPPDEY6B150C
110/1800
121/1858
turbocharged
intercooled
6.871
760
1415*877*1025
main engine
BMMPPDEY6B165C
120/2300
132/2374
turbocharged
intercooled
6.871
760
1415*877*1025
main engine







Y6B specification
Model
BMMPPDEY6108ZLCA
BMMPPDEY6B150C
BMMPPDEY6B165C
Type
Vertical,in-line,water-cooled,4 stroke
Intake way
exhaust gas turbocharge,intercooled
No. of Cylinder - bore*stroke
6-108*125

Dispalcement (L)
6.871
Compression ratio
17.5:1
Continuous power/speed (kW/r/min)
90/1500
110/1800
120/2300
One-hour power/speed (kW/r/min)
99/1548
121/1858
132/2374
Min.specific fuel consumption (g/kW·h)
≤200
Specific Oil Consumption (g/kW·h)
≤0.8
Crank shaft rotation direction
counter-clockwise(seen from the power output end)
Net mass (kg)
750
Overall demension(L*W*H) (mm)
1415*877*1025
1408*877*1062
1415*877*1025
Ruduction gearbox to be matched
HC65,135,120C…
135,120C…
HC65,120C…









































90~120KW Six Cylinder Marine Diesel Engine90~120KW Six Cylinder Marine Diesel Engine90~120KW Six Cylinder Marine Diesel Engine90~120KW Six Cylinder Marine Diesel Engine

We can supply all scopes of marine engine,from 10kw-3000kw.If you need engines,don't miss us.Please feel free to contact us.We can provide you best service and prices!



Equip China,Power World!

 90~120KW Six Cylinder Marine Diesel Engine
