Fully Auto Foam Production Continuous Foam Plant
Main Usage of Continuous Foam Plant:
This equipment is used in soft PU products. Foaming Density Range:8-70kg/CBM.The ideal Foam products are involved with Furniture,
Shoes, Bra and Electricals field, also suitable for Mattresses, Sofa, Package, Cloths and Car industry. User can save over two hundred different of recipes,
To adjust and change them by user at any time.User can remote control it by internet that reduce production cost scientific and directly.PLC Digital Touch Screen or Electric Control System. This machine can change the formulation no need stop machine , no need test flow, The degree of resistance to yellow can reach 3~5 international standard,
cooperatethe customer’s request to offer diffrend formulation, and trainng the foaming engineer .
Parameters of Continous Foam Plant :
Max.Output Capacity: |
200~350kg/min(Continuous Type) |
Mixer Total Power: |
37kw |
Max.Mixing Speed: |
2500~6000r/min |
Foaming Type: |
Trough & Sprayer |
Save Formular Q.T.Y.: |
13 Groups. |
Foaming Size: |
W2300mm*H1300mm(Width Adjustable) |
Control System: |
PLC Digital Touch Screen(Made In TaiWan) And Electirc Control System. |
PPG Tank: |
5Ton*1Set. |
POP Tank: |
5Ton*1Set. |
PPG+CACO3 Tank |
5Ton*1Set |
Fire-Retardard Tank |
1Ton*1Set |
TDI Tank: |
4Ton*1Set. |
MC Tank: |
1 Ton*1Set. |
Silicone +Water Tanks: |
150L*2Sets |
T-9+Amine+Color (A.B.C): |
150L*5Sets |
Side Wall Size: |
L18m*H1200mm |
Fallplate: |
L7m*W0.98~2.4m(Adjustable) |
Foaming Platform: |
L2000mm*W3000mm*H700mm |
Conveyor Line: |
|
Side/Bottom Paper Feed & Rewind System: |
2Sets. |
Walkway: |
W500mm*L18m |
Air Valves |
Euro Standard |
Chiller(Both Cooling & Heating System): |
1Set*1.5HP(Made In TaiWan) |
Side Film Lifting System: |
1Set. |
Foaming Density Range: |
8~70kg/Cubicmeter. |
Match With Block Cutter: |
1Set. |
Total Motor Power: |
Approx 125kw. |
Air Compressor: |
Match With 7.5KW(10HP)*1Set |
Machine Name.: |
Continuous foam plant |
Floor Space Required: |
L45m*W5m*H4.5m. |
Videos in Youtube :
https://youtu.be/xTddFs7OGCM
https://youtu.be/JdxjwNKmoNc
https://youtu.be/wjkz8gC2tSY
Packaging & Shipping
Packing: Wooden Box or Hard Paper Film Packing
Shipping: By sea, by air, by express (DHL, UPS, EMS Fedex etc)
Our Services
1.We can help to design the layout of the machine base on your factory.
2.we can send 2-3 experience engineers to install and test the machines completely well before back.
3.We have very professional foam engineer can train you people how to make foam if require .
4.we can train your person how to operate and maintain the machines.
5.We can offer the machine operation manual .
6.we can help to buy the best raw material if you require
The EliteCore Machinery Manufacturing Co.,Ltd is one of the China main professional manufacturer of polyurethane foam machines,
especially foam making machines,foam cutting machines,3D CNC foam contour cutting machines are gained a lot of reputation from
all over the world. As an outstanding manufacturer of China polyurethane foam Machinery Industry,EliteCore Designs Machinery From Standard Models
To High-Tech 3D CNC machines.Whenever you are looking for high quality foam machines,EliteCore is truly your only one choice from China.EliteCore always your reliable partner.
Exhibition :
CE certificate :
