Brief Introduction:
ZBW series non-contact compensated voltage regulator use high power thyristor (silicon controlled rectifier) instead of mechanical and carbon brush to control and adjust voltage, which can realize 2000KVA high capacity. Max compensation range is ±50%, efficiency is up to 99%. This type of voltage regulator is the newest regulator which has full protection functions, high reliability and adaptability, continuous working time over one hundred thousand hours without any failure.
Technical Parameters
| AC input | Input Voltage Range | 3-phase 304V-456V |
| Frequency | 47hz-63Hz | |
| AC output | Rated voltage | 3-phase 4-wrie 380V/220V |
| Regulation precision | ±1-5%(optional) | |
| Waveform distortion | Without additional waveform distortion(static) | |
| Efficiency | ≥98% | |
| Response time | 20-100ms | |
| Power factor | 0.8 | |
| Output Delay | Stabilize voltage first, then output | |
| Protections | Overvoltage or low voltage | Voltage at output phase over 10%, cutting off output or continuous steering bypass |
| Overload | Electronic detection,cutting off output within 3 minute of overload | |
| Missing phase | Automatic cut-off | |
| Bypass | Continuous automatic bypass in case of failure | |
| Indication | Voltage | LCD display for A, B, V, ∑ABC 3 phases with virtual value |
| Current | LCD display for A, B, V, ∑ABC 3 phases with virtual value | |
| Working Condition | stabilized voltage/electric supply | |
| Abnormal | over voltage, low voltage, overload, fuse wire broken | |
| LCD Interface | intelligent operation interface, easy to set and research various parameters | |
| Working Modes | with two working modes, stabilize voltage and electric supply mode | |
| Overload capacity | 5 times of rated current for 1 second | |
Product Features
Fast response | 12 BMP high speed AD collection, collect 128 points for each cycle, MCU handling digital processing and calculation, quick compensation with digital module |
Various adjustment modes available | simultaneous adjustment; separate adjustment; automatic adjustment |
No waveform distortion | non-contact design, same frequency, phase lock, sine wave added compensated |
Resistance to harmonic interference | effective voltage detection |
Wide load range | adapted to resistive load, capacitive load, inductive load |
Low operating noise | ≤45Db |
Communication interface | RS485 |
Product Dimensions
Model | Capacity (KVA) | Input Voltage (V) | Output Voltage(V) | Rated Output Current(A) | Size (mm) L*W*H | Weight (kg) |
ZBW-S10 | 10 | 380V±20% (three phase) |
3Φ4W+G380V 3Φ4W+G220V 3Φ4W+G200V 3Φ4W+G460V ±7%; Optional | 15 | 350×600×750 | 140 |
ZBW-S20 | 20 | 30 | 160 | |||
ZBW-S30 | 30 | 46 | 180 | |||
ZBW-S50 | 50 | 76 | 390×650×870 | 195 | ||
ZBW-S80 | 80 | 120 | 460×650×1200 | 316 | ||
ZBW-S100 | 100 | 152 | 330 | |||
ZBW-S120 | 120 | 180 | 380 | |||
ZBW-S150 | 150 | 228 | 700×700×1600 | 450 | ||
ZBW-S180 | 180 | 273 | 490 | |||
ZBW-S200 | 200 | 300 | 530 | |||
ZBW-S250 | 250 | 342 | 1100×800×2100 | 630 | ||
ZBW-S320 | 320 | 486 | 720 | |||
ZBW-S400 | 400 | 608 | 810 | |||
ZBW-S500 | 500 | 760 | 910 | |||
ZBW-S600 | 600 | 912 | 1050 | |||
ZBW-S800 | 800 | 1216 | 1800×1000×2100 | 1300 | ||
ZBW-S1000 | 1000 | 1520 | 1650 | |||
ZBW-S1200 | 1200 | 1824 | 1900 | |||
ZBW-S1400 | 1400 | 2127 | 2400×1000×2000 | 2100 | ||
ZBW-S1600 | 1600 | 2431 | 2300 | |||
ZBW-D3 | 3 | 220V±20% (single phase) |
220V±7%; Optional | 14 | 300×600×600 | 20 |
ZBW-D5 | 5 | 23 | 28 | |||
ZBW-D10 | 10 | 45 | 50 | |||
ZBW-D20 | 20 | 91 | 80 | |||
ZBW-D30 | 30 | 136 | 100 | |||
ZBW-D50 | 50 | 227 | 660×660×1400 | 140 |
