GOGO ATC Pneumatic Frl Units BC2000 1/4 Inch Manual Drain Pressure Gauge Airtac Type Air Filter Regulator Lubricator
- T/T Credit Card
You May Like
-
GOGO ATC High Quality Filter Regulator and Lubricator Auto Drain 3/8 Inch MIDI Type FRL Air Source Treatment Pneumatic
-
GOGO AT Pneumatic High Pressure Air Regulator Inlet Port Thread 1/4 Inch BSP Treatment Units QTYH-08 0~35bar With Pressure Gauge
-
GOGO ATCPneumatic High Pressure Regulator Inlet Port Thread 3/8 Inch BSP Air Treatment Units QTYH-10 0~35bar With Pressure Gauge
-
GOGO ATC High Quality Air Filter C30810 Screw Air Compressor Dedicated Filter
-
GOGO ATC High Quality Oil Gas Separator KB8038 Screw Air Compressor Accessories Oil Core
-
GOGO ATC High Quality Oil Gas Separator KB8634 for 15KW/20A Screw Air Compressor 10-50HP Universal Oil Core
Product Details
| Brand Name | GOGO ATC | Place of Origin | Zhejiang, China | |
| Model Number | BC2000 |
Product Description
GOGO ATC Pneumatic frl with cotton cartridge filter Manual drain
With pressure gauge airtac type air filter regulator lubricator
Model: BC4000 1/2 inch
* * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * **
1.Specification
1)Type:AC2000,BC2000 ,BC3000,BC4000
2)Air filter regulator lubricator
3)Nice replacement for Airtac type
4)Size:1/8"~1/2"
5)ISO & CE
Bore(mm) | AC2000 | BC2000 | BC3000 | BC4000 |
Operating Fluid | Air | |||
Joint Pipe Bore | G1/4" | G1/4" | G3/8" | G1/2" |
Filtering Element Roughness | 40u | |||
Range of Adjustable Pressure | 0.05~0.85MPa | |||
Max.Adjustable Pressure | 0.95MPa | |||
Ensured Pressure Resistance | 1.5MPa | |||
Operating Temperature Range | 5~60 | |||
Capacity of Filter Cup | 15cc | 60cc | ||
Capacity of Oil Feed Cup | 25cc |
| 90cc |
|
Suggested Lubricating Oil | ISO VG 32 or same level oil | |||
Weight | 0.7KG | 0.9KG | ||
Body Material | Aluminum Die-casting Forming | |||
Container Cup Material | PE | |||
Protective Cup Material | - | Iron | ||
Filter | AF2000 | BF2000 | BF3000 | BF4000 |
Regulator | AR2000 | BR2000 | BR3000 | BR4000 |
Lubricator | AL2000 | BL2000 | BL3000 | BL4000 |
2.Dimensions
3. Picture
