Stainless Steel Accumulator for Chemical Pump

Stainless Steel Accumulator for Chemical Pump thumbnail-1
Stainless Steel Accumulator for Chemical Pump thumbnail-2
Stainless Steel Accumulator for Chemical Pump thumbnail-3
Stainless Steel Accumulator for Chemical Pump thumbnail-4
Stainless Steel Accumulator for Chemical Pump photo-1
Stainless Steel Accumulator for Chemical Pump photo-2
Stainless Steel Accumulator for Chemical Pump photo-3
Stainless Steel Accumulator for Chemical Pump photo-4
US$ 3 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
GOGO
Place of Origin:
Zhejiang, China
Model Number:
NXQ
Contact Supplier Request Quote Chat Now
Ningbo Fenghua Gogo Automatic Trading Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOGO
Place of Origin Zhejiang, China
Model Number NXQ
Type Hydraulic Accumulators

Stainless Steel  Accumulator for chemical pump





Specification



NXQ  hydraulic accumulator

Stainless Steel Accumulator for chemical pump

Stainless Steel Accumulator for chemical pumpStainless Steel Accumulator for chemical pump






The accumulator can be accumul  ated the energy replenished leakage provided constant pressure sucked in pulse pressure etc It can be used for auxiliary energy power and urgent energy power
Series NXQ rubber bag accumulator is adopted rotary-press forming with seamless pipe technique It features compact structure beautiful look light weight small inertia and steady function The design is conformed to JB/T7036-93 "Technieal condition for hyd-accumulator" It is used oil-base hydraulic oil medium in system The bag of cooler is charged with nitrogen for normal working ranged into -10~+70
Easy operation large series production capacities welcome to orders
  Model description
  Stainless Steel Accumulator for chemical pump
  Technical specification and outer dimension
  Stainless Steel Accumulator for chemical pump

Model Pressure Mpa Capacity L Basic size  Weight kg
M Φ H L
NXQ-L0.63/* 10
20
31.5		 0.63 M27X2 89 50 305 4.5
NXQ-L1/* 1 M27X2 89 50 430 6
NXQ-L1.6/* 1.6 M42X2 152 66 361 12.5
NXQ-L2.5/* 2.5 M42X2 152 66 428 15
NXQ-L4/* 4 M42X2 152 66 538 18.5
NXQ-L6.3/* 6.3 M42X2 152 66 708 25.5
  Charge tool (according to accumulator of pressure for use)

Pressure of accumulator Mpa Model of charge tool Pressure scale range  Precision degree
10 CQJ-16 P=0~16 1.5
20 CQJ-25 P=0~25 1.5
31.5 CQJ-40 P=0~40 1.5
  Application and feature

Application Feature
Sucked shock of hydraulic Accumulator is normal mounted before the directional valve or the eylinder It can suck or slow sudden exchanging clirection or suddden stopping of the cylinder for shock perssure
For hydraulic air spring  Spring rate KT is equal equivalent cylinder action force causing by gas bag pressing for differential pressure divided equivalent cylinder of position movingmean KT=(P2-P1)A/(V1-V2)A(Pa.m) In formula P1P2-min operating pressure and max. operating pressure Pa A effective area of equivalent cylinder m2 V1.V2-volume of gas for pressure P1and pressure P2 m3
Reducing flowate of pulse and pressure  Piston pump a little gears contacting gear pump relief valve etc in hydraulic system They can cause hydraulic pressure flowrate for pulse Mounting accumulator can be reduce hydraulic pulse and noise

For heat expand compensator		 When the temperture is raising up in sealed hydraulic system The hydraulic oil is produced expand of volume Because fluid expand ratio is general bigger then pipe material expand ratio It will cause oil pressure for raising up The avvumulator can suck up fluid volume of increment protect exceed pressure ensure satety When the temperature is reducing the fluid will contract The accumulator will supply fluid for requiring in system
Improving on frequency property  When hydraulic system is adopted compensative of pre variable mechanism time constant is for bigger the avvumulator can quickly release pressure for improving on frequency property



1





Packing



Stainless Steel Accumulator for chemical pump





Shipment and Payment



Stainless Steel Accumulator for chemical pumpStainless Steel Accumulator for chemical pump







About us



Stainless Steel Accumulator for chemical pump

Stainless Steel Accumulator for chemical pumpStainless Steel Accumulator for chemical pump

Stainless Steel Accumulator for chemical pump



Skype: ATCGOGO

HYDRAULIC ACCUMULATORS
