Full-Automatic SMT Solder Paste Printer, SMT PCB Printing Machine Before the Pick and Place Machine

FOB Price

USD $28000 - $55000 / Set

1 Set(Min.Order)

Supply Ability 5 Set / Sets per Month
Port Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
Delivery Detail:35 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Introduce：

ETA ETA-4034 is a high precision automatic solder paste printer, correspond to industrial 4.0 and MES system.through a higher level of automation,achieve zero defect.

Features：
1, High positional accuracy, repeated positioning accuracy ±0.01mm; printing accuracy 0.025mm. 2, Support glue printing,Automatic control improves production efficiency, quality control and saves production cost.
3, Automatic PCB calibration,Squeegee pressure adjustable,Automatic printing,Automatic stencil cleaning. 4, Programmable motor controls separation speed and distance among squeegee,stencil and substrate,to realize multi-method separation.
5, Multi-functional PCB positioning system for convenient and accurate PCB positioning. 6,Programmable PCB lifting platform ensure the PCB to lift to a proper height. 7,Adopt company independently developed suspended print head with automatic pressure adjustment system. Support on-line real time pressure feedback and automatic squeegee pressure balancing. Accurate pressure control ensures perfect paste forming effect. 8,Applicable PCB types:LCD TV,STB,LED,family cinema,vehicle electronics.besides general electronics products.
9.SMEMA standard.
TOP Advantage:

 Simple: combined with advanced international concepts, based on the Oriental-designed operating system, easy to learn.
 Expertise: learn imported reflow oven’s   advanced design concepts, and the machine core components are using imported top brands.
 Hedging: Import hardware configuration,low failure rate in production,more than a decade service life.4. Safety: Based on the general rules of international design, close to imported reflow rating, the highest security level.
Stable: mature software, hardware and top production processes ensures stability of each equipment.

Model	ETA-4034	ETA-5134	ETA-6534	ETA-6561	ETA-1200(LED)	ETA-1500(LED)
Frame Size(mm)	470370~737737	470370 ~ 737737	470370 ~ 850750	470370 ~ 850850	470370 ~ 1500750	470370 ~ 1800750
PCB Size(mm)	5050 ~ 400340	5050 ~ 510340	5050 ~ 650340	8050 ~ 650610	8050 ~ 1200350	8050 ~ 1500350
PCB Thickness	0.4~6mm
PCB Warpage	900±20mm
Transport Direction	Left-Right; Right-Left; Left-Left; Right-Right
Transport Speed	Max 1500mm/s
Power Supply	AC:220±10%,50/60HZ,3Kw
Control Method	PC Control
Dimension(mm)	122013551500	122013551500	133015301500	133015301500	220012001500	250012201500
Weight	Approx: 1250kg	Approx: 1250kg	Approx: 1300kg	Approx: 1300kg	Approx: 1500kg	Approx: 1800kg

Certifications

Packing & Delivery

※ Standard Wooden Package withVacuum

Shipping Way:

※ By air, for sample and small package,international express like DHL, UPS, EMS...
※ By sea, for large package and quantity;
※ Other ways as customer requested. Delivery Time:
※ 35 Days.
