Mini Excavator Hydraulic Pump V10 V20 Wholesale
- Ningbo
- T/T Credit Card
You May Like
Product Details
| Brand Name | NVICKS | Place of Origin | Zhejiang, China | |
| Model Number | V10-P-1-P-1-A-20-L | |||
| Fuel | Gasoline | Power | Hydraulic | |
| Usage | Oil | Theory | Axial Flow Pump | |
| Standard or Nonstandard | Standard | |||
| Pressure | High Pressure |
Product Description
Mini excavator hydraulic pump V10 V20 wholesale
Feartures:
The V10&V20 Fixed Displacement Hydraulic Vane pump has a specially designed inlet flow path which gives it uniform oil acceleration and high speed capability. This, combined with a compact modular design, makes the V10&V20 an ideal pump for medium to low-pressure mobile and industrial applications as a main system pump or as a pilot auxilary pump.
Eaton/Vickers V10&V20 Series Vane Pumps Features:
-Pressure balanced vane design
-Modular construction
-Wide range of displacements
-Double pump option
Eaton/Vickers mini rotary vane pump V10&V20 Series Vane Pumps Benefits:
-Low noise and long life
-Ease of repair and serviceability
-Wide range of applications
-Compact for limited space installation
Eaton/Vickers V10&V20 Series Mini Rotary Vane Pumps Applications: Power Units, Power Steering, Skid Steerers,
Lift Trucks, Balers
Can be exchanged with the original ones completely.
Welcome your inquiry!
| Mdel descriptin | |||||||||||
| V20 V10 Mdel descriptin | |||||||||||
| F3- | V20 V10 | - | 1 | F | -- | B | 1 | --- | -- | — | -- |
| Special sealing parts | Series |
mounting Flange |
Inlet prt connections | Displece-ment | Outlet port connections of high pressure | Shaft Extension | Outlet port position (Viewed from cover end) | Design No. | Shaft rtation direction | ||
|
V10or V20 |
1=2-bolt flange Arresting end di- ameterΦ 101.6(4)(standard) 6=2-bolt flange, Arresting end di-ameter Φ82.6 (3.25) |
(V10only) B=G1 P=1/2-14-NPTF S=1-1/16-12UN-2B V20 Only)B=G1-1/4 P=1-1/4-11-1/2-NPTF S=1-5/8-12UN-2B |
For V10 1,2 ,3,4,5,6,7 For V20:5,6,7,8, 9,10,12,13 |
(V10 only:)B=G1/2 P=1/2-14-NPT S=3/4-16UNF-2B (V20 Only) B=G3/4 P=3/4-14-NPT S=1-1/16-12UN-2B | 1=Straight keyed shat 11=Splined shat 38=Splined shat (V20 only) 3=Woodruff key shat 62=Spined shat | A=Oppsite inlet prt B=90°CCW from inlet C=In line with inlet D=90°CCW rom inlet |
11-V20 series 20-V10 series |
Viewed from shart end L=CCW Omit or right hand rotation | |||
