Dip Coating Machines
- Shenzhen port Guangzhou port
- T/T Credit Card
You May Like
-
2020 new hot dip continues galvanizing machine
-
Dip Release Paper Coating Machine
-
Dip Coating Machine with Touch Screen Digital Controller
-
Dip Conformal Coating Machine For Bopp Adhesive Tape
-
touch screen programmable dip coating machine
-
Lab Desktop Dip Coater Coating Machine with 0 to 200mm Distance
Product Details
| Brand Name | HONGJIN | Place of Origin | Guangdong, China | |
| Certification | CE | |||
| Warranty | 1 YEAR | |||
| Weight | about 15kg | Dimension(L*W*H) | 220(L)*310(W)*410(H) | |
| Condition | New | Voltage | 220V | |
| Power(W) | 50w | |||
Product Description
Product details
This machine is mainly used in sol-gel method to prepare many kinds of film materials on the same substrate. The different solution is placed on the rotary table, by setting the coating process, the substrate into solution dip coatings, the coating after the rotary table will be just below the solution film under a layer of automatic rotation to the substrate, the substrate drops into the solution dip coating, in order to complete the follow-up film. Films of different solutions, different materials and mixed immersion plating.
For example, the 123456 coating can be arranged in sequence according to the solution, or the 136425 coating can be arranged in accordance with the mixing. A single coating process can use up to 6 kinds of solution (material) to make multilayer film. The process parameters such as immersion, coating parameters, solution rotation and interval time of different layers are fully controlled by coating process
Many factors affect the film thickness, including viscosity, density, specific gravity, pulling speed and angle of dip solution, solvent viscosity, density, evaporation rate and environmental temperature and drying conditions.
| Product technical parameters |
| Lifting height: | 0-300mm |
| Lifting speed range: | 1 ~ 9999 μm / s, minimum resolution 1 μm / s |
| Falling speed range: | 1~9999 μm/s, minimum resolution 1 μm/s , position accuracy: <0.01mm |
| Speed accuracy: | ± 0.01% |
| Immersion time: | 1 ~ 3200 s |
| Number of coatings: | 1 to 1000 times |
| Coating interval: | 1 ~ 3200 s |
| Power: | AC 220V 50Hz |
Company Profile
Hongjing Inspection Instrument Co., Ltd. is a high-tech enterprise which specializes in producing, developing and simulating various kinds of environmental testing equipment, mechanical testing equipment, luggage testing equipment, electronic and electrical testing equipment, wire and cable testing equipment and large-scale non-standard testing equipment design and automatic control.
