Solar Panel Programmable Constant Temperature and Humidity Environment Testing Machine
US$ 15,000 - 18,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HOTOTECH
Place of Origin:
Guangdong, China
Model Number:
HTPV-17-2
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Customization Industrial High Low Temperature Humidity Cycling Testing Chamber/ Testing Machine for pv ModuleUS$ 18,000 - 20,000MOQ: 1 Set -
Real-time Curve Display High-Low Temperature Test Chamber With PV Module TestingUS$ 15,000 - 18,000MOQ: 1 Set
-
PV Module/Solar Panel UV Preconditioning System Test Chamber/Testing Machine With IEC61215-2:2016 StandardUS$ 12,000 - 18,000MOQ: 1 Set
-
IEC 61215 Strength Testing Machine Solar PV Module Mechanical Load TesterUS$ 9,999 - 19,999MOQ: 1 Set
-
IEC61215 Solar Panel PV Module STC and NMOT Measurement / Solar Panel Testing Machine / PV Module Testing EquipmentUS$ 600 - 10,000MOQ: 1 Set
Brand Name
HOTOTECH
Place of Origin
Guangdong, China
Model Number
HTPV-17-2
Company logo
Product Description
Solar panel programmable constant temperature and humidity environment testing machine
Prupose
It's to determine th ability of the module to withstand the effects of long-term penetration of humidity
Technical specifications
| Product Name | Solar panel programmable constant temperature and humidity environment testing machine |
| Testing standard | IEC61215-2:2016 testing standard |
| Temperature range | 85℃±2℃ |
| Relative humidity | 85%±5% |
| Temperature fluctuation | ≤±1℃ |
| Temperature deviation | ≤±1℃ |
| Temperature uniformity | ≤2℃ |
| Humidity range | 30~95%RH |
| Relative humidity deviation | ≤±2.5%RH(humidity 75%R) |
| Common moisture point | 85℃/85%RH continue time≥1000h 90℃/90RH continuity ≥1000h |
| Control ways | Touch screen+PID intelligence control |
| Testing sample quantity | 12 PCS |
| Outer material | Stainless steel(SUS #304) |
| Outer material | Steel plate baking finish |
| Calculus | PID automatic calculus |
| Thermal insulation material | Hard foam and glass wool |
| Communicate interface | RS232 or RS-485 communicate interface |
| Air supply circulation system | Motor |
| Interface show | Touch screen control |
| Electricity | 380V 60HZ |
Products images show
Clients visit photos
Exhibition
Package show
Nameplate
