IEC 61215-2:2016 standard Mechanical Load Tester /Pressure strength testing machine /testing equipment for solar panel
purpose
It's use to verfication and ensure module under the different intall instal angle suffer wind, snow, or cover ice etc static, dynamic load ability . width use to check PV module resistance press, strength test , adopt dynamic holding press technical , simulate load test, in order to products under the load statue resistance press ability
standard
It's satisfy IEC61215,IEC61646 etc standard
specifications
| Machine table exterior size | L 320 × D 180 × H 195 cm |
| Test positive load | the max 5400 Pa |
| negative load | the max 24 00 Pa |
| Material | Aluminum extrusion structure |
| The max test sample size | 120 × 240cm |
| Calibrator | 350 kg |
| DC constant voltage and current power | 0~100Vor 0~15A adjustable;the resolution 0.001V or 0.001A;the voltage setting accurate more than 0.1V,current setting value accurate more than 0.1A. |
| Cylinder number | 4 groups, in total 8 pcs |
| Cylinder outside diameter | 80mm |
| Pneumatic cylinder single the max pressure | more than 6 bar |
| Pneumatic cylinder single group the max put out force | more than 300kg |
| Pneumatic cylinder stretch stroke | 150 mm |
| sucker number | 8 groups , in total 32 PCS |
image show
Dongguan Hong Tu Instrument Co.,Ltd , specializes in developing and producing sales of testing instrument for helmet ,photovoltaic , leather ,footwear ,luggage ,sport equipments, metal and rubber , we have firm connections and full cooperation from China's National Third-part Quality Inspection and Notarization Center on producing and developing high-precision testing machines
We treasure the value of good quality , reasonable price and efficient service with customer satisfaction. we expert ourselves in providing our customers the best suitable testing designs and high quality testing machines to make you the utmost profit
Please feel free to contact us for any enquires from our wide range of products
Products show in our workshop
1.High quality and best after-sell service
2.100% quality inspection before delivery
3.Managment Innovate
4.Strong R & D team
5.Can handle customers's feedback problems and doubt timely
6.Our testing machine have one year Warranty time
FAQ
Q: Are your company a trading or factory ?
A: Factory +Trade (integration) , 8 years focusing n test machines field and exporting experience , OEM also acceptance for us
Q: After an order is placed , when to deliver
A: Generaly about 30 work days
Q: Do you have any certificate about your factory ?
A: We are already got SGS , ISO 9001 and some testing machine's patent certificate
Q: What about the Warranty with after-sales service ?
A : We have one year warranty time , when the testing machine have problems and the customer notice us
We received the customer problems feedback ,we will reply and help customer to solve the problem at first time
Q: How about your testing machine's data accurate ?
A: About our testing machine's data accrate, customers can be assured, because many government's lab by our factory help to plan and established
