UL94 Horizontal and Vertical Burning Machine for Plastics Flammability Test
- Shenzhen
- T/T Credit Card
You May Like
-
Factory Price Equipment Dielectric Strength Machine Electric Strength Tester
-
Instrument For Dielectric Strength Tester to Test Electric Strength UL1310
-
Apparatus For Dielectric Strength Tester to Test Electric Strength
-
IEC60332 Single Wire Vertical Flame Test Equipment
-
IEC60332-1 Single Cable Vertical Burning Test Chamber
-
IEC60332 Electric Wire Vertical Burning Test Equipment
Product Details
| Brand Name | BONAD | Place of Origin | China | |
| Model Number | BND-FX94 |
To be packed in wooden box
Product Description
UL94 Horizontal and Vertical burning machine for plastics flammability test
Appliance:
The horizontal and vertical burning tester is a simulated combustion performance safety test project according to the standards of UL 94, IEC 60695-11-4, 60695-11-3 standard.
The horizontal vertical burning tester is a Bunsen burner with a specified size and a specific gas source (methane or natural gas). The sample will be placed as horizontal or vertical position, burn it in certain height and angle several times, it is evaluated by the burning for the combustibility and fire risk.
The horizontal vertical burning tester is mainly used to grading the flammability of V-0, V-1, V-2, HB, and 5V materials. Suitable for research, production and quality inspection of electrical and electronic products and their components, such as lighting equipment, low-voltage electrical appliances, household appliances, machine tools, electrical machinery, electrical connectors and accessories, as well as insulation materials, engineering plastics or other solids. Combustible materials industry.
Features:
Burner | Φ9.5mm ± 0.3mm Bunsen Burner
|
Angle | 0°,20°,45° manual switch |
Flame Height | 20mm ± 2mm to 180mm±10mm (switchable)
|
Burning Time | 0-999.9s±0.1s (adjustable) |
Burning Gas | 98% methane gas(can also use liquefied petroleum gas)
|
Flow / pressure | Flow meter and pressure gauge |
Temperature Range | 0~1000℃ |
Flame Temperature | From 100℃±5℃ to 700℃±3℃ (in 44s±2s and 54s±2s) |
Thermocouple | Φ0.5mm thermocouple 2pcs(50W and 500W) |
Vent | Individual ventilation |
Standard | UL94-2010,IEC60695-11-3,4 international standard |
Studio | 0.75 cbm |
Dimension | 1100mm×700mm×1300mm |
Power | AC220V ,50Hz, ≤500W |
How to order
1. Place the order and pay directly if you have no question to the product. 2. If you have some questions, don't bother to send me a message to ask. 3. After you have paid the money, we will deliver the goods as soon as possible. |
Packaging and Shipping
1. Aluminium box and carton box, careful and tight package, make sure the package is intact. 2. The package will be shipped by DHL/Fedex/TNT/EMS/UPS/China post/EF-Express/Special line, as you have chose in the order. 3. The shipping time is different, it depends on the distance bewteen us. At usual, exclude the preparing time, the goods would be sent to you in 5days. |
