Customized Black Test Corner With Thermocouple Based on IEC60335
- Shenzhen
- T/T Credit Card
You May Like
-
Electric Heating Drum Drying Oven for 300 Degree
-
ASTM G153 Standard UV Accelerated Aging Test Chamber, UV Testing Machine
-
Accelerated UV Lamp Tester For Sunlight Resistance, Fabric, Coating
-
IEC60332 Single Cable Vertical Burning Test With Bunsen Burner
-
Discount! IEC 60065 Dielectric Strength Tester
-
IEC60065 Socket-outlet Torque Balance Apparatus
Product Details
| Brand Name | BONAD | Place of Origin | Guangdong, China | |
| Model Number | BND-CYJ | Power | Electronic |
To be packed in aluminum foil box
Product Description
Customized black test corner with thermocouple based on IEC60335
Customized black test corner with thermocouple based on IEC60335
Introduction:
1. Black test corner is based on IEC60335-1: 2004 (national standards GB4706.1-2005) to design and manufacture.
2. Black test corner is mainly used to provide a variety of electrical and electronics products the standard requirements of environmental conditions for temperature rise testing. The black test corner can be customized according to the actual sample as different distributions specifications, test corner number of measurement points and dimensions.
Spectifications:
Dimension | 400*400*400mm / 600*600*600mm / 600*600*1000mm / 800*800*1000mm / 1000*1000*1000mm / 1000*1000*1200mm |
Thermocouple | <0.3mm, K/T/J type (according to your choice) |
Thermocouple layout | All lead to a link bank (or select thermocouple plug and socket) |
Temperature test strip | Brass strip with 15mm diameter and 1mm thickness |
Temperature test point | 20 / 32 / 48 / 72 points (Or as your requirement) |
Test point layout | 100mm*100mm / 76mm*76mm (Or as your requirement) |
Plywood | Thickness 20mm, front painted matt black,grey plate on back |
Active part | Install 4 active wheels |
Temperature patrol meter | Optional |
How to order
1. Place the order and pay directly if you have no question to the product. 2. If you have some questions, don't bother to send me a message to ask. 3. After you have paid the money, we will deliver the goods as soon as possible. |
Packaging and Shipping
1. Aluminium box and carton box, careful and tight package, make sure the package is intact. 2. The package will be shipped by DHL/Fedex/TNT/EMS/UPS/China post/EF-Express/Special line, as you have chose in the order. 3. The shipping time is different, it depends on the distance bewteen us. At usual, exclude the preparing time, the goods would be sent to you in 5days. |
Company Profile
14 Stanards drafted and issued by Labthink -- 100 Patents granted by Labthink -- 410 m2 Laboratory to provide testing services -- 20 years experienced lab technicians to provide solutions -- 12 months warranty -- Remote Services (Free of Charge allthrough lifetime)
