IEC60529 Simulated Environment Sand Dust Proof Resistance IP5X IP6X Test Chamber
- Shenzhen
- T/T Credit Card
You May Like
-
Electronic Programmable Dustproof Test Chamber for IEC60529
-
Stainless Steel IP5X/IP6X Sand Dust Resistance Test Equipment
-
IEC60529 Programmable Vacuum Sand and Dust Test Chamber
-
IEC60529 IPX8 High Pressure Immersion Water Test Tank
-
IPX7 Temporary Immersion Test Equipment Conformance to IEC60529
-
Mobilephone Click Lineation Life Test Machine
Product Details
| Brand Name | BONAD | Place of Origin | Guangdong, China | |
| Model Number | BND-SC | Power | Electronic |
To be packed in wooden box
Product Description
IEC60529 Simulated Environment Sand Dust Proof Resistance
IP5X IP6X Test Chamber
IEC60529 IP5X IP6X sand and dust test chamber
Introduction:
The dust and sand test chamber is conformance to IEC60529 IP5X and IP6X dust proof test. The test chamber is mainly used for electronic and electrical products to assess weather the shell and seal in the sand control during the test equipment and components can ensure good performance.
model | BND-SC-600 | BND-SC-800 | BND-SC-1000 | BND-SC-X | |
Inner Dimension (L×W×H) mm | 600×600×600 | 800×800×800 | 1000×1000×1000 | As Customized | |
technical index | Outer dimension | H1850*D1250*W1450(mm) | |||
Material | SUS304 stainless steel plate | ||||
PID Digital Controller | |||||
| Power | AC220V,50HZ | ||||
Blower Time | |||||
Vibration time | 0-9999.9H (Adjustable) | ||||
timing range | 0.1-9999.9H | ||||
Dust dosage | 2-4kg/m³ | ||||
Dust dimensions | <=32µm33%.32µm-250µm67% | ||||
Mesh Diameter | 50um | ||||
Wire Spacing | Less than 70um | ||||
vacuum system (Optional) | pressure gauge, air filter regulator, triple pieces of Voltage, connecting pipe | ||||
