Walk-in Environmental Test Chamber for Temperature And Humidity Test

Name: Walk-in Environmental Test Chamber for Temperature And Humidity Test
Brand: BONAD
Availability: InStock

FOB Price

US$ 5,000 - 90,000 / Set

1 Set(Min. Order)

Port Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	BONAD		Place of Origin	Guangdong, China
Model Number	BND-HCEK		Power	Electronic

Packaging Details

Wooden Box

Product Description

Walk-in Environmental Test Chamber for Temperature And Humidity Test

Product Description

Introduction:

Walk-in rooms are perfect for any product testing that requires a higher volume than standard units.Our walk-in rooms feature fast temperature change rates, high humidity and explosion resistant applications.

Features:

• This series product use polyurethane panel,the inner surface is made of stainless steel,the surface of the shell is made of color steel.It has firm structure and easy installing,with a elegant appearance and novel design.

• We adopt import fittings as our main control fittings to ensure oven quality.

Use the newest cooling conrol model in the international , it can adjusted the cooling power of the compressor reach to 0%-100% automatically to realize low energy consumption run of the machine.

• Configured with Multi-panel sliding doors and inboard type Illumination,, it provides good observation for the specimen's working.

• Size and performance can be customized by customers.

• This system has simple operation and convenient to install,training and Maintenan.

Product Show

Walk-in Environmental Test Chamber for Temperature And Humidity Test

Detailed Information

Walk-in Environmental Test Chamber Parameters:

purpose	Non-standard testing instrument(It is applicatable for the testing of electronics,household appliances, automotive electronics and materials to prosess whole machine or sample test for kinds of climatic factor.

model		HC−EK−01Series	HC−EK05− 05Series	HC-EK-10Series
volume of the workroom(m³)		customized according to customers requirements.
Specifications	temperature range	-20°C -40°-60°C~+100°C
	humidity range	20~98%R.H(+20°C~+80°C)
	temperature deviation	≤±2°C
	humidity deviation	±2.0%RH(>75%RH),±3±2.0%RH(>75%RH),±3.0%RH(≤75%RH)0%RH(≤75%RH)
	temperature fluctuation	≤±0.5°C
	heating rate	≥3-5°C/min(better than national standard )
	Cooling rate	≥1-1.5°C/min(better than national standard )
	refrigeration compressor	Hermetically sealed compressor "Taikang” imported From French / Semi-hermetic compressor Gulun of German
	refrigerant	environmental protection HFC-R404A/HFC-R23
	cooling mode	Air-Cooling or water cooling
	Airflow mode	single cycle,stem extension,Stainless Steel centrifuge blade.
	mode of refrigerant	cell refrigeration/double refrigeration
	Water supply	built-in water tank
	dehumidification	freeze
	control system	Fuji of Japan's /a LCD touch screen of Japan's OYO /LCD touch screen of Korea (TEMI880)
	Temperature Control	procedure&program
Security device		Multiple alarm device such as:electric leakage,water shortage,overheat,over pressure of compresor,overcurrent
Standard Configuration		internally heated hollow glass observation window
Power Supply		380V±10%50Hz 3P+N+G
Standards Applied		GB2423.1-89 Basic environmental testing procedures for electrician electronic products(Test A Test method of low temperature) GB2423.2-89 Basic environmental testing procedures for electrician electronic products (Test B Test method of high temperature ) GB/T2423.3-93 Basic environmental testing procedures for electrician electronic products (Test method of muggy temperature ) GB/T2423.4-1993 Test Db Test method of alternate muggy temperature GJB150.3-86Test method of military equipment environmental testing (Test of high temperature ) GJB150.4-86 Test method of military equipment environmental testing (Test of low temperature )

Walk-in Environmental Test Chamber Demision Table:

Volume	Inner size(D×W×H)	Workroom Outer(D×W×H)	Complete(D×W×H)	Door(D×W×H)

8M3	2000×2000×2000	900×2300×2550	(3900~4550)×2300×2550	1000×2000*
10M3	2500×2000×2000	3400×2300×2550	(4500~5050)×2300×2550	1000×2000*
12M3	2500×2500×2000	3400×2800×2550	(4500~5050)×2800×2550	1000×2000*
14M3	3200×2000×2200	4100×2300×2750	(5100~5750)×2300×2750	1000×2000*
16M3	3200×2000×2500	4100×2300×3050	(5100~5750)×2300×3050	1000×2500*
20M3	3600×2500×2200	4500×2800×2750	(5500~6150)×2800×2750	2000×2200
22M3	3600×2500×2500	4500×2800×3050	(5500~6150)×2800×3050	2000×2500
25M3	4000×2500×2500	4900×2800×3050	(5900~6550)×2800×3050	2000×2500
26M3	4000×3000×2200	4900×3300×2750	(5900~6550)×3300×2750	2500×2200
32M3	5200×2500×2500	6100×2800×3050	(7100~7800)×2800×3050	2000×2500
34M3	5200×3000×2200	6100×3300×2550	(7100~7800)×3300×2550	2500×2200
38M3	3600×3500×3000	4650×3800×3550	(5650~6300)×3800×3550	2500×2500
44M3	4400×4000×2500	5450×4300×3050	(6450~7100)×4300×3050	2500×2500
46M3	4400×3500×3000	5450×3800×3550	(6450~7100)×3800×3550	2500×2500
48M3	4800×4000×2500	5850×4300×3050	(6850~7500)×4300×3050	2500×2500
84M3	7000×4000×3000	8100×4300×3550		4000×3000
300M3	10000×5000×6000	11100×5300×6550		4000×4000

Packaging & Delivery

Packaging: Wooden Box

Delivery:Shipped in 4~6 weeks after payment
