Home > Products > IP Waterproof Test equipment > ip code protection drip box turntable
ip code protection drip box turntable
- 100 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
You May Like
-
IEC 60529 spray jet nozzle
-
iec 60529 IPX5 and IPX6 spray jet nozzle
-
vertical rain drop IP waterproof test chamber for IPX3 IPX4
-
iec water jet spray nozzle ,ip waterproof test chamber for ipx6 ipx5
-
iec 60529 ipx3 ipx4 waterproof testing equipment waterproof iec jet spray nozzle
-
IPX3 IPX4 camera waterproof rain spray tester
Product Details
Brand Name | BND | Place of Origin | Guangdong, China | |
Model Number | ipx test chamber | Power | Electronic | |
Safety Aluminum foil box for ip code drip box turntable
Product Description
ip code protection drip box turntable
Product information:1 pressure vessel: stainless steel tank, diameter 0.8 meter, height 1 meter.
2 pressure adjustment range: 0 ~ 5bar (can be customized).
3 pressure system: stainless steel pump + frequency converter.
4 pressure gauge accuracy: 0.25 degree, range: 6bar.
5 test time: 0-99min.
6 maximum limit pressure: 6bar.
7 pressure protection: pressure switch protection.
8 connect to the water supply equipment by 3/4 high pressure steel wire hose connection
Technical parameters:
Turntable diameter | Ø600mm |
Sample holder | Ø600mm |
Turntable speed | 1rpm |
Tiltable angle | 15° |
Test angle of rotation | 90° , continuous rotation |
Adjustable height of the adjustable telescopic tube | 300mm, 1200mm-1500mm |
Body material | Industrial aluminum alloy |
Dimensions (LxDxH) | 800X800X1500mm |
Stage network type | |
Aluminum base with casters | |
Reversible control, rotational movement control by the control cabinet |
Our service
1.High quality guarantee.
2.Shipment with professional documents.
3.Packing as your request, with photo before shipment.
4.Reply within 48 hours and provide solution within 3 working days
4.Professional after-service from our engineers.
5.Warranty period 12 monthes.
Our advantages
Professional technology support.
Full experience of large numbers containers loading in Chinese sea port.
Fast shipment by reputed shipping line.
Best service after shipment with emails.
Best knowledge about Safety Testor and other related machine in USA/UK/INDIA/AUSTRALIA/CANADA/SOUTH AFRICA ETC
We are professional test equipment manufaturer in China with excellent experience and skills, also have best quality products
Our concept
1.Client is first. We are trying to bring maximum profit to our clients and offer best quality products
2.Credibility is the most important.
3.Quality control is our life.
4.Great sense of responsibility.
We will not only supply products service to you but also help you solve any other problem what we can do ,we can meet in this large world is our fate ,so we have been friends ,looking forward to meeting you !
Our factory
If you need any other messages we are not show here ,please dont hesitate to contact us below ,we will glad if we can help you ,thanks !
Company Profile

14 Stanards drafted and issued by Labthink -- 100 Patents granted by Labthink -- 410 m2 Laboratory to provide testing services -- 20 years experienced lab technicians to provide solutions -- 12 months warranty -- Remote Services (Free of Charge allthrough lifetime)
