Shrink film+Polyfoam+Carton/Plywood Case/Customer Requirements
Our difference with others
1) All bolts & Nuts are SS304
2) All Piston are hard anodizing
3) Packing:Foam + small carton box to protect goods
4) Laser fonts on body
Actuator Model：electric actuator
Actuator Material：Aluminium Alloy
Rotary Angle: 90°
Output Torque : 20NM-2000NM
Motor Power：specific
Action Time: specific
Rated Current: specific
Voltage: DC24V/AC110V/AC220V/AC380V
Insulation Resistance：100MΩ/500VDC
Voltage Resistance Rating：1500VAC/minute
Protection Level: IP67
Working Temperature ：-20ºC~+60ºC
Circuit Control type：ON/OFF type
Control options: standard type: limit position switch/A type: with mid-position switch/B type: with potentiometer/C type: with potentiometer and mid-position switch/intelligent type: 4-20mA
Build in thermal protection, rotary degree 360 installation position
Optional function: dehumidifier
All Rotary actuators are Rack and Pinion design and are available in 90 deg. These have high torque to weight ratio for faster cycle times.
Ideal for ball valve, butterfly valves, dampers, indexing mechanisms.
Main body housing rack and pinion is made from solid bar stock or close grained casting. The outer surface of the actuator is specially designed and has a smooth surface (special design on demand) for typical pharma application - hence cleaning becomes very simple.
Features:
• Ball valves / Butterfly valves of required sizes & materials and can be coupled with pneumatic actuator (single acting, spring return or double acting) and solenoid valves.
• Dom type position indicator for on-off indication can also be provided with above assembly.
• Above valves can also be provided with Pneumatic / Electro-Pneumatic Positioner with input supply of 3-15 Psi / electrical signal of 4 to 20 mamps for percentage opening of the valves.
Technical Specifications:
• Double acting / single acting spring return actuators
• Degree of rotation: 90 Deg
• Rack & pinion mechanism
• High torque & durability.
• ISO standard with NAMUR mounting arrangement
