Home > Industrial Equipment & Components > Engine & Part > Engine > SINOTRUK Q235 Carbon Steel Tanker Material 6*4 Sinotruck Fuel Tank Truck
SINOTRUK Q235 Carbon Steel Tanker Material 6*4 Sinotruck Fuel Tank Truck
US$ 40,000 - 45,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
sinotruk
Place of Origin:
Shandong, China
Model Number:
ZZ1257N4647C
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO TIANJIN LIANYUNGANG any port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SINOTRUK 10 Tires+1 Spare Tire Tire Specification 6*4 Oil Tank Truck Fuel TruckUS$ 40,000 - 45,000MOQ: 1 Set -
SINOTRUK Oil Pump 6*4 Oil/fuel Transport Tank Truck for Hot SaleUS$ 40,000 - 45,000MOQ: 1 Set
-
SINOTRUK HOWO Water Truck 20000L Water Tanker Size Howo Water Tank Sprinkler Trucknk TrucksUS$ 40,000 - 45,000MOQ: 1 Set
-
H-Q SINOTRUK HOWO 420hp EURO III Mine Dump Truck 70ton for SaleUS$ 61,000 - 69,000MOQ: 1 Set
-
SINOTRUCK HOWO TRACTORUS$ 65,000 - 65,000MOQ: 1 Set
Brand Name
sinotruk
Place of Origin
Shandong, China
Model Number
ZZ1257N4647C
Product Description
SINOTRUK Q235 carbon steel Tanker material 6*4 sinotruck fuel tank truck
| Product Name |
SINOTRUK Q235 carbon steel Tanker material 6*4 sinotruck fuel tank truck |
| Driving Type | 6×4,left hand drive |
| Chassis model | ZZ1257N4647C |
| Weights | |
| Payload (kg) | 24000 |
| Curb weight(kg) | 12400 |
| Dimensions | |
| Wheelbase(mm) | 4600+1350 |
| Overall Dimension(mm) | 9800×2500×3200 |
| Box dimension | 20CBM |
| Max speed(km/h) | 80 |
| Engine | |
| Engine model | WD615.95E (336HP) |
| Engine type | 4 stroke water-cooled,inter-cooling |
| No. of cylinders | straight-6 cylinders |
| Displacement(L) | 9.726L |
| Max. output (kw) | 247kw |
| Drive Line | |
| Transmission | HW15710,10 forwards,2 reverse gear,HW76 Cab |
| Steering | ZF8098,With power steering |
| Brake system | Air brake |
| Cab | |
| Cab | HW76 |
| Standard configuration |
Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; with A/C;shock-absorbers |
| Whole instrument desk, digital meters,and so on | |
| Axle | |
| Front axle | HF7 |
| Rear axle | HC16 |
| Tire specification | |
| Tire specification | 12.00-20 standard tire,10 tires+1 spare tire |
| Specification fuction of water truck | |
| Tanker shape | Ellipse water tanker |
| Tanker material | Q235,carbon steel |
| Tank compartments | 4 compartments |
| Manhole | Man way access hole on top of tank;1 units DN500mm manhole |
| Man walk way | With skid resistance man walk way on top of tank |
| Horse reels | Two 75 ft hose reels at each side of the truck |
| Pump | Oil pump |
