Home > Products > tool steel > 1.2344 Tool Steel cold work steel
1.2344 Tool Steel cold work steel
- 100000 Ton / Tons per Month
- shenzhen
- T/T L/C PayPal
- Nak80/10ni3mncual die steel
- HPM75 mould steel
- S7 Performance Cold Working Die Steel
- AISI 4140 Hot Rolled Alloy Round Bar
- The manufacturer of the anchor bolts for the iron tower provides U-shaped screw embedded parts, steel structure embedded prefabricated parts, and samples can be provided according to the drawings
- Production of Monel400 N04400 Monel K-500 N05500 Monel Alloy Bar Round Steel
Product Details
Brand Name: | otai steel | Place of Origin: | China | Model Number: | DC53 Tool Steel |
Type: | Other, tool steel | Application: | Tool Steel Bar | Technique: | Cold Drawn |
Standard: | AISI, ASTM, DIN, GB, JIS | Alloy Or Not: | Is Alloy | Special Use: | Free Cutting Steel |
Steel Grade: | DC53 Tool Steel |
Product Description
JIS DC53 tool steel china supplier and stockholders, Otai special Steel are Special steel china suppliers of DC53 steel in round bar, flat bar, sheet , plate and steel block. we can saw cutting DC53 as your requirements size. DC53 is improved new type of cold work die steel from SKD11 . The technical specification in Japanese industrial standard JIS G4404.
Cold work DC53 tool steel overcomes the insufficient of SKD11 high temperature tempering hardness and toughness of weakness, DC53 tool steel will fully replace SKD11 tool steel in the field of general and precision mould . Its toughness is 2 times of SKD11, DC53 toughness is more prominent in the cold work die. Made of DC53 tools steel rarely appear crack and craze, greatly improving the service life.
The DC53 tool steel has a uniform distribution of fine carbides. It has great galling and wear and fatigue resistance. It has also a High temper resistance to support PVD & nitride surface treatments. And it has Machining and grinding properties are superior to most other tool steels.
Related Specifications JIS G4401 (2000) DC53 tool steel
DC53 steel Form of Chemical composition
C(%) | Si(%) | Mn(%) | Cr(%) | Mo(%) | V(%) |
0.95 | 1.00 | 0.40 | 8.00 | 2.00 | 0.30 |
DC53 Form of Supply
For Cold work tool steel DC53, we can supply the steel round bar, steel flat bar, steel sheet, plate and square block. DC53 tool steel round bar can be sawn to your required length and size. Rectangular steel pieces can be sawn from flat bar or plate to your specific sizes. Ground tool steel bar can be supplied, providing a quality precision finished bar to tight tolerances.
Round
sheet
Plate
Square
DC53 steel Applications
The Cold work DC53 Tool Steel is found in Punches & dies, Draw & forum dies, Shear blades, Shredder knives, Thread & form rolls, Cold heading dies and Mill rolls & slitters.
Heat treatment JIS DC53 steel
The DC53 Tool steel heat treatment process can be broken down into 4 segments, Hardening (quench) & Tempering.Annealing & Normalized.
Most customers only need make the Hardening (quench) & Tempering for DC53 steel aplication.
DC53 tool steel heat treatment
JIS DC53 tool steel Forging
Slowly and uniformly Heat the DC53 tool steel to 700°C (1292°F),then rapidly heat the DC53 steel to 900-1040°C(1652-1904°F). After forging slowly cool down.
DC53 tool steel Hardening | quenching
Heat slowly the DC53 tool steel to 850°C(1562°F), Soak thoroughly at the temperature. the brought up to 1030°C(1886°F)oil quenching or air cool.
Tool steel DC53 Tempering
Commonly performed DC53 Tempering is in a high Vacuum controlled convection furnace. The temper is perfect after Hardening. conducted as soon as the part can be hand at about 45° C (120° F) to 65° C (150° F). by High temperature tempering and hardening, hardness tool steel DC53 can reached 65 HRC MAX. common application ,we advice the Hardness no higher than 62HRC. DC53 steel DC53 tool steel Tempering data only for reference as below:
DC53 tool steel Annealing
Normal D53C annealing condition delivery, hardness 255HB MAX. When finished the DC53 Steel tool, then can heat treatment to appropriate hardness.
Regular size and Tolerance
1) Hot Rolled round bar | |||
Diameter (mm) | Diameter Tolerance (mm) | Diameter (mm) | Diameter Tolerance (mm) |
6.4~15.8 | -0.038 ~0.038 | 181~<206.2 | 0~1.6 |
15.8~<77.6 | 0~0.10 | 206.2~<257 | 0~2.4 |
77.6~<103 | 0~0.15 | 257~<307.7 | 0~3.2 |
103~<181 | 0~0.78 | ≥307.7 | 0~4.7 |
2) Hot Rolled steel plate | |||
Thickness (mm) | Thickness Tolerance (mm) | Thickness (mm) | Thickness Tolerance (mm) |
≤25.4 | -0.41~0.79 | >127~152 | -1.60~2.39 |
>25.4~76 | -0.79~1.19 | >178~254 | -1.98~3.18 |
>76~127 | -1.19~1.60 | >254~305 | -2.39~3.96 |
Others have not specified size, pls contact our experienced sales team.
Processing
DC53 tool steel round bar and flat sections can be cut to your required sizes. Ground steel bar can also be supplied, providing a high quality tool steel precision ground tool steel bar to your required tolerances. DC53 Tool Steel is also available as Ground Flat Stock / Gauge Plate, in standard and nonstandard sizes.
Contact our experienced sales team to help you with your DC53 questions
by email or telphone. The questions will be reply in 24 hours.
