Testing Equipment
9802-K Ethylene Oxide Gas Chromatography
Application
9802-K Ethylene oxide gas chromatography comes with reasonable structure, stable and reliable performance, simple operation and easy maintenance. It can be widely used in the production and scientific research departments such as petroleum, chemical industry, pesticide, medicine and hygiene, commodity inspection, environment protection, college and so on. It is to detect organic solvents, the solvent residue of printed packaging materials and the purity or content of a single solvent.
Standards
QBT 2929, YBB 00132002,YY0469-2011
Specifications
Item |
Technical Parameters |
Detector |
hydrogen flame detector(FID)(optional for others) |
Detector Parameters |
Sensitivity Mt≤3×10-12g/s( n−hexadecane);baseline drift≤1×10-13 A/30min ;noise≤ ≤2×10-14A |
Chromatographic column |
Ethylene oxide analysis column,30m×0.32mm×0.5um, |
Head space |
20 Bits |
Column oven size |
240×210×240mm |
Temperature range |
4℃~450℃(Optional in 1 ℃ increments) |
Temperature controlling accuracy |
0.1% |
Temperature gradient |
1℃ |
Temperature control method |
Six-way temperature control, program heating steps: 16 steps, stroke rate: 0.1 ~ 60 ℃ / min Time setting: 6000 (min) |
Air generator (optional) |
Oil-free air generator with degreasing and water purification equipment, 3L / min |
Hydrogen generator (optional) |
Gas production 300ml / min, purity 99.999% |
Nitrogen cylinder and pressure reducing valve |
Contains 99.999% high-purity nitrogen and pressure reducing valves (preferably purchased locally) |
Air connection |
Φ3mm gas pipe |
|
Standard material
|
Ethylene oxide standard |
workstation |
Dual-channel, anti-control workstation |
Capillary injection system |
Split / splitless, with diaphragm cleaning function |
Features
- Economical and practical, excellent performance and quality.
- Adjustable gas circuit pressure, stable flow, with multiple gas circuit system of nitrogen, hydrogen, air, exhaust, shunt , cleaning.
- LCD screen displays temperature in real time.
- Cellular overall structure design, convenient to install and maintenance.
- Advanced noise resistant system, work quietly.
- Over-temperature protection function, with program protection and circuit protection double insurance.
- With data workstation, professional software support and powerful data analysis function.
- Display working condition and chromatogram curves; curves can be zoomed and moved.
- Professional test report, can export PDF file.
- Manual button switch, its function is equal to “start collecting”, which is convenient for sampling.
- Easy to operate detector and baseline calibration.
Service
- Free packaging inspection technical support
- Instrument one year warranty, free software upgrade service, free technical support for life
- Free to come to the factory to train the equipment operation, qualified graduates will issue a graduation certificate, free room and board
- Instrument "trade-in" policy and provision of spare instruments in case of failure
- Set up a testing center (CNAS L8185) to provide customers with sample detection and sample data comparison service
- Set up a reference material development center to provide customers with instrument calibration and calibration services
Note: GBPI is always committed to product innovation and improved performance, so accordingly product technical specifications are subject to change without notice. GBPI reserves the right to amend and the final power of interpretation.
GBPI, you reliable partner!
