Ultraslim Notebook Type Black and White Ultrasound Scanner Machine Bw-8
Negotiable
/ Unit
1 Unit(Min.Order)
- 500 Unit / Units per Month
- Zhegnzhou
- T/T Other
- 5 days
You May Like
- Saikang Table Lamp Battery Operated
- Surgery 2 Vaporizers Anesthesia machine, Different types Anesthesia machine, Portable Anesthesia
- Hongyang Medical ICU Ventilator with Air compressor ZXH-600D 12.1 inch Folding Screen
- Hongyang Medical ICU Ventilator with Air compressor ZXH-600 12.1 inch Touch Screen
- Hongyang Medical Portable Anesthesia machine GSM-II with Ventilator
- Hongyang Medical Portable Anesthesia machine GSM-II Veterinary Use
Product Details
Brand Name: | BENEMED | Place of Origin: | China | Model Number: | BW-8 |
Type: | First-Aid Devices |
Product Description
Features:
15 inch LCD displayer
Built-in medical report
Three transducer connector ports
Printer output
Work with batteries
DICOM 3.0 optional
Technical Specification
Measurement & Calculations
Others
B&W mode: | B,M,2B,B/M,4B |
Gray: | 256 |
Display: | 15"LCD monitor |
Transducer Frequency: | 2-11MHZ |
Digital Technology: | Wide-angle imaging Panotamic focusing technology Rolling M technology |
Scanning Depth: | 220mm |
Functions | |
Cine-loop: | 334 frame cine loop memory |
USB ports: | 2 |
Zoom: | Pan zoom |
THI: | Tissue Harmonic Imaging |
Qopt: | One-key Optimize |
DICOM: | DICOM3.0 |
Print: | Report print for text&graph&image |
Measurement & Calculations
B mode: | Distance,angle,area,volume,trace length,distance ratio |
M mode : | Distance,time,slope,HR |
Software packages: | Abdomen,OB,Gynecology,small Part,Cardiac |
Others
Transducer connector: | 3 active transducer connector ports |
Peripheral ports: | Video,2 USB ports,1 networking port,1 power inlet, 1 equiptential terminal |
Standard configuration: | BW-8 main unit, Convex probe, Power adapter |
Power supply: | 100-240~50/60HZ<100VA |
Options: | Transvaginal probe, Linear probe, Micro convex probe |
Dimensions(main unit): | 360mm(W)*360mm(L)*90mm(H) |
Packing dimensions: | 415mm(W)*435mm(L)*140mm(H) |
Net weight: | 4.5kg |
Gross weight: | 5.5kg |
