Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
KMY
Model Number:
KMY801C
location::
Guangdong
color::
multicolor
is customized::
yes
Supply Ability
Supply Ability:
3000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
giftbox, carton box
Lead Time :
Shipped in 0 days after payment
Introduction
KMY801C provide a secure and convenient card service with the existing GSM or internet network. It is the best choice for use in office, retail shop, small café/restaurant and also much more other locations for business service. The service covers almost all the financial services and daily payment. It can be used for financial transaction/payment, bank card management, loyalty card management, top up, e-voucher/lottery/ticket sell, utility bill payment and so on.
Key features
GSM/GPRS or Ethernet communication
DES/3DES encryption algorithm
DUKPT key management solution
Flexible design on hardware and software
Telephone function and handset optional
External PCI PIN pad, scanner, card reader etc.
Specifications
CPU
32 bit ARM7 CPU
Memory
NandFlash 64MB, 56MB available; SDRAM32MB, all available
Display
128*64 dot matrix yellow-green backlit LCD display
Keypad
24 silica gel keys: 12 telephone keys,4 direction keys,8 function keys
Magnetic card reader
Internal magnetic card reader, support ISO7812-2
Track 1/2 or 2/3, Track 1/2/3 (option)
IC card reader
Internal IC card reader, support ISO7816-1-2-3-4
2 chip card slot for PSAM card, support ISO7816-1-2-3-4
Internal RF card reader, support TypeA card; ISO7816 T=0, T=1
Printer
Built-in 58mm thermal printer
High speed up to 70mm per second
Communication
GPRS wireless module, support GPRS/USSD
1 SIM slot, support GSM 850/900/1800/1900MHZ
Port: 1 RJ-45(Ethernet), 2 RJ11 port(RS-232 definition)
Operating environment
Temperature: –10°C~ 45°C
Humidity: up to 80%, non-condensing
Power
9V 3A DC Adapter, 8.5V 2200mA Li-ion battery
Dimension
23cm (L) x15cm (W) x 8cm (H) with handset
23cm (L) x11cm (W) x 8cm (H) without handset
weight
1 kg
Peripherals
PCI PIN Pad, Barcode reader, card reader etc.
Security
PSAM card for PIN encryption and identity verification
Employs DES and 3DES algorithm
DUKPT Key Management for PIN security
If abnormally opened, security data will be erased
