High Quality Medical ECG Machine with 10.1 Inch Touch Screen

Name: High Quality Medical ECG Machine with 10.1 Inch Touch Screen
Brand: BENEMED
Price: Negotiable

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Product Details

Brand Name:

BENEMED

Place of Origin:

China

Model Number:

BM-ECG1212

Features:

10.1 inch (1024*600) color TFT LCD with touch screen, Rapid preview of ECG wavfeform before printing
Seamless connection with HIS
Data output in format of FDA-XML , DICOM,DAT, BMP, JPG, SCP
WLAN/LAN connection for data transmission via ftp
ECG algorithm certified by AHA/MIT/CSE database & 30 year application
Particular ECG analysis as per age difference
One touch operation via touch screen or strike
Compatible with external VGA, PC keyboard,mouse and bar code scanner

Specification:

Leads:	9/12leads simultaneous acquisition
Sampling Rate:	16000Hz/ channel/second
A/D Resolution:	24 bits
HR Constant:	30-300bpm
Time Constant:	≥3.2s
Polarizing Voltage:	±600mv
Input Impedance:	≥50 MΩ(10Hz)
Frequency Response:	0.01-300Hz
Noise Level:	≤12.5μV (p -p)
DFT Filter:	0.01/0.05/0.32/0.67 Hz
Pacemaker Detection:	Amplitude:±750μV-±700 mV, Width 50μs-2.0ms Sampling Frequency:16000Hz
Power Supply:	AC input with external power adaptor of 100-240v,50/60Hz Rechargeanle Lithium battery (4400mAh) supporting 400 exams
Recording Speed:	5/6.25/10/12.5/25/50 mm/s
Recording Paper:	Z-fold 210295mm100sheets Roller type 210mm*20/30m
EMG Filter/Low Pass:	25/35/45/75/100/150/270/300Hz
LCD Display:	10.1 inch TFT color LCD (1024*600) with touch screen
CMRR:	≥120dB
