High low temperature tensile strength tester
Purpose:
This high and low temperature tensile testing machine is suitable for universal materials testing, for tensile, compression, bending, peeling, tearing, peeling, bursting, fatigue test on metal rod, metal plate, rubber, PU, leather, plastic, foam, sponge, water-proof material, cable, wire, fabric, nettle, non-woven, etc..
Test items:
metal high temperature tensile test metal low temperature tensile test rubber high & low temperature tensile test other material high & low temperature tensile test
Meeting standards:
GB/T4338-1995 ISO783:1989 metal high temperature tensile test GB/T13239-2006 ISO15579:2000 metal low temperature tensile test GB/T228-2002 ISO6892:1998 metal room temperature tensile test
Specification:
Model |
XB XB-OTS-8000 |
Capacity |
500N,1kN,2kN,5kN,10kN,20kN,50kN can option |
Resolution |
1/500,000 |
Load accuracy |
±0.25%F.S |
Test speed range |
0.001~500mm/min or 1~1000mm/min |
Temperature range |
room temperature-75℃ ~250℃ |
Inner chamber dimension |
W300×D350×600mm |
Temperature control accuracy |
±2℃ |
Min. temperature value |
0.1℃ |
Cooling recycle system |
90W motor, Stainless steel lengthen roller, multi-wing fan blade |
Heater |
1000W×2 fin-style radiator tube stainless steel heater |
Thermal insulation material |
high temperature chamber: glass fiber; low temperature chamber, hard foam. |
Coolants |
low temperature chamber, environmental coolants |
Chamber material |
inner side will be SUS304# mirror, the outside will be cold steel plate with painting |
Temperature control mode |
P.I.D self-adjusting mode and SSR control |
Temperature controller |
button input, LED digital display output |
View window |
double layer view window(180×220mm) |
Dimension WxDxH |
950×800×2400mm |
Weight |
295kg |
Power |
AC220V,12A |
1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while considering of sea transportation, we can extend 2 months for our customers.
If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized
machines according to your requirements. And we can also put your logo on the machine.
4. Do you have a branch company or service office in my country?
We have offices in the belowing:
The US Office: XIN BAO INSTRUMENT (US) CO.,LTD
Tel: 001-612-402-1218
Vietnam: XIN BAO INSTRUMENT INDUSTRY(VIETNAM)CO.,LTD
Tel:+(848)66764653 Fax:(+848)37527888
Address:248 no.1A Road,An Lac-Binh Tri Dong Residence,B Ward, Binh Tan Disrtict, HO Chi Minh City, Vietnam.
Singapore Dealer: Surveillance Inspection & Testing Services Pte Ltd
Tel: (+65) 96857857
Address:No. 5 Jalan Kilang Barat #08-06 Petro Centre Singapore, 159349
Italy Dealer :AMSE SRL
Tel:+39-011-2730000
Address: Strada della Cebrosa 86, 10156 Torino Italy
Suzhou Branch: XIN BAO INSTRUMENT SUZHOU BRANCH
Tel:0512-67078249 Fax: 0512-67078749
Address: The First Garden B5 Buildings,Wuzhong Road 2588,Wuzhong District, Suzhou City Jiangsu Province
Nanjing Branch: XIN BAO INSTRUMENT NANJING BRANCH
Tel: 025-85657886 Fax: 025-85657896
Address: Room 539, Excellence Building, 688 Zhujiang Road, Xuanwu District, Nanjing City, Jiangsu Province
Taizhou Branch: XIN BAO INSTRUMENT TAIZHOU BRANCH
Tel: 0576-88522556 Fax:0576-88522556
Address: No.68, Gaoyuan District, Jiaojiang District, Taizhou City, Zhejiang Province
Taiwan : TAIWAN XIN BAO INSTRUMENT CO.,LTD
Tel:04-24731563 Fax:04-23804092
Address: No. 551-1, 4, Central Road, Taichung City, Taiwan
5. How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our officail website directly.
Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
Please feel FREE to contact us if you have any needs. And welcome to visit our OFFICIAL WEBSITE at:
www.ots-testequipment.net
If you want to know more information...
Please leave a message below and click " SEND "
Thanks for your time and attention!
