ZWZP Electric High Temperature Steam Globe Control Valve
Electric High Temperature Steam Globe Control Valve
This high temperature control valve is composed of an electric actuator and a high precision low flow resistance regulating valve body. The electric high-temperature steam globe control valve has the advantages of tight closing, compact structure, light weight and convenient maintenance.The BCST electric high temperature control valve is equipped with a 3810 series (or PSL series) electric actuator and a small precision regulating valve body. It accepts a standard signal of 4-20 mA or 1-5 V·DC to convert the current signal into a corresponding linear displacement.The electric high temperature control valve adopts a balanced valve plug structure, which is widely used in the occasions where the flow rate is large, the temperature is high, and the leakage amount is not strict.
Technical Parameters of BCST High Temperature Steam Globe Control Valve:
DN(mm) | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | |
Seat Dia.(mm) | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | |
Rated Kv | Single-seated | 6.9 | 11 | 17.6 | 27.5 | 44 | 69 | 110 | 176 | 275 | 440 | 630 | 875 | 1250 |
Cage Guided | 6.3 | 10 | 16 | 25 | 40 | 63 | 100 | 155 | 250 | 370 | 580 | 900 | 1300 | |
Allowed Pressure Difference (MPa) | Single-seated | 3.8 | 3.2 | 3 | 2 | 1.8 | 1.5 | 1.4 | 1 | 0,7 | 0.6 | 0.5 | 0.3 | 0.1 |
Cage Guided | 6.4 | 6.4 | 5.2 | 5.2 | 4.6 | 4.6 | 3.7 | 3.7 | 3.5 | 3.1 | 3.1 | 2.6 | 2.2 | |
PN(MPa) | 1.6、2.5、4.0、6.4、10.0 | |||||||||||||
Rated Travel(mm) | 16 | 25 | 40 | 60 | 100 | |||||||||
Bonnet Type | high temperature type(+250～+450℃) | |||||||||||||
Seal Packing | PTFE, flexible graphite | |||||||||||||
Plug Type | Single seated,cage guided | |||||||||||||
Flow Characteristic | Equal percentage,linear | |||||||||||||
Actuator Type | 3810 series electric actuator,PSL series electric actuator | |||||||||||||
Actuator Parameter | Power voltage:220V,input singal:4-20mA or 1-5V·DC,output signal:4-20mA·DC | |||||||||||||
Protection level:IP65,Explosion-proof:ExdⅡBT4(ExdⅡBT6 customized),manual function: handle | ||||||||||||||
Ambient temperature:-25～+70℃,ambient humidity:≤95% | ||||||||||||||
