Specification of 105 Inch Curved TV Smart Curved OLED TVS 4k Curved OLED TVS Supplier

size

105 inch

Display parameter

backlight style

LG curved module

resolution

5120(H)×2160（V)

viewing angle

160°

color

88.8m

brightness

550cd/m2

contrast ratio

5000:01:00

Response time

1ms

Effective display area

2470.5mm(H) x 1075.0mm(V)

Hardware parameter

mainboard configuration

 (620.81)

Network port (RJ45) port: One Group

Audio input port (YPbPr) port: One Group

composite video port (CVBS) port: One Group

Computer audio input port (PC AUDIO) port: One Group

Computer video loss (VGA) port: One Group

Computer video input port (HDMI) port: Three groups

Analog signal input port（RF）port: One Group

Coaxial (COAX) port: One Group

EARPHONE OUT port: One Group

Memory card (TF) port: One Group

Multimedia (USB.3.0) port: One Group

Multimedia (USB.2.0) port: Three groups

Features and Specification

Android 5.1

Scanning system: PAL

sound system: BG, DK, I, MN

Decoding: 3D digital comb filter 3D image motion noise reduction 3D motion adaptive comb filtering and so on

The horn features

Speaker type: built-in speaker high bass

Speaker Power: 10W×2

input voltage

Alternating current: 100～240V 50/60Hz

whole power

800W≤

standby power

＜0.5W

net weight

111kg

gross weight

141.5kg

size of bare machine (L*W*H)

2495×1080×73MM

size of the package(L*W*H)

2695×1480×45MM

Size of hanger(L*W)

825×600MM

operating environment

relative humidity ≤ 80%

Storage Humidity -10～60℃

The use of humidity 0～40℃
